5365-01-165-1411
Sleeve Spacer
5365011651411 011651411 S-1079-M04-F02-I 0933-164 9321-A-194-1B
A tubular shaped item with a round or hexagon peripheral shape having two flat bearing surfaces perpendicular to the axis of the centrally located hole. It is designed to maintain a predetermined distance between assembled parts. The item may be with or without flange(s) of any peripheral shape. The overall length must exceed 25 percent of the outside diameter or distance across peripheral flats of the body. (When the length, outside diameter, and/or distance across peripheral flats are designed as a tolerance, the maximum dimension will be used to determine compliance). For items having other than a round or hexagon peripheral shape, see SPACER, PLATE. Excludes items with lubricating features, see BEARING, SLEEVE and BUSHING, SLEEVE. See also BUSHING, TAPERED; SPACER, RING; WASHER, FLAT; and WASHER, (as modified). View more Sleeve Spacer
June 2023
3
Marketplace 5365-01-165-1411
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-165-1411 5+ Documents (More...)
Photo 1/3 5365-01-165-1411 Photo 2/3 NSN 5365-01-165-1411 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 5365-01-165-1411 RQST NE Updated Every Day 5365-01-165-1411 RQST
BUY NE FedMall Updated Every Day 5365-01-165-1411 RQST NE Updated Every Day 5365-01-165-1411 RQST
Restrictions https//www.nsnlookup.com /fsg-49/fsc-4925/us https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-01-165-1411
participating marketplace vendors https//www.nsnlookup.com https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-01-165-1411
Sleeve Spacer 5365011651411 011651411 Restrictions Approved Sources Datasheet Management https/
Restrictions 5365-01-165-1411
5365-01-165-1411 is a Sleeve Spacer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5365-01-165-1411
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5365-01-165-1411
- US Coast Guard (C911)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- C006
- US Air Force (FXGG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Supplementary Collaborators:
- HD
Approved Sources 5365-01-165-1411
- Part Number
- Manufacturer
- Status
- S-1079-M04-F02-I
- Manufacturer
- 04729 - Unicorp. (Active)
- Primary Buy
- Primary Buy
- 9321-A-194-1B
- 06540 - New Haven Mfg Corp Amatom Electronic (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 0933-164
- 07187 - Honeywell International Inc. (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5365-01-165-1411
- Characteristic
- Specifications
- FIIG
- Specifications
- A045A0
- Body Inside Diameter [ADAS]
- 0.1910 Inches Minimum And 0.2070 Inches Maximum
- Body Outside Diameter [ADAR]
- 0.3700 Inches Minimum And 0.3800 Inches Maximum
- Corner Shape [BZLX]
- Square All Corners
- Material Document And Classification [MDCL]
- Qq-A-225/3,T3 Fed Spec Single Material Response Overall
- Material [MATT]
- Aluminum Alloy 2011 Overall
- Overall Length [ABHP]
- 0.4950 Inches Minimum And 0.5050 Inches Maximum
- Style Designator [STYL]
- Solid, Plain, No Outside Flanges
- Surface Treatment Document And Classification [STDC]
- Mil-A-8625,Type 2 Mil Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Anodize Overall
Weapon Systems (WSDC) 5365-01-165-1411
DLA Procurement Analysis 5365-01-165-1411
Management Data 5365-01-165-1411
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-01-165-1411
Freight Information 5365-01-165-1411
5365-01-165-1411 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 013120. A Sub NMFC of F. It has a NMFC Description of ALUMINUM ARTICLE NOI SUB 6. 5365-01-165-1411 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05380 which rates the freight between FCL and LCL. 5365-01-165-1411 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-01-165-1411 is not classified as a special type of cargo when transported by water. 5365-01-165-1411 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5365-01-165-1411 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
