5365-01-143-6868
Ring Spacer
5365011436868 011436868 TT415-0147 PIECE 5 518-4674751 ITEM 22
A circular-shaped item designed to maintain predetermined distance between assembled parts and/or for distributing pressure or preventing endwise movement between member parts. It has a solid cross-section and two flat parallel bearing surfaces. The distance between the bearing surfaces perpendicular to the axis of the centrally located hole shall not exceed 25 percent of the outside diameter. The diameter of the centrally located hole must exceed 75 percent of the outside diameter. Excludes laminated items. For items manufactured from impregnated graphite or lubricated nonmetallic materials, excluding felt or plastics, see GASKET. For items manufactured from lubricated plastics, see BEARING, WASHER, THRUST. For items manufactured from lubricated felt, see FELT, MECHANICAL, PREFORMED. Excludes DISK, VALVE; INSULATOR WASHER; and SHIM. See also SPACER, PLATE and SPACER, SLEEVE. View more Ring Spacer
November 2023
4
Marketplace 5365-01-143-6868
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-143-6868 5+ Documents (More...)
BUY NE FedMall Updated Every Day 5365-01-143-6868 RQST NE Updated Every Day 5365-01-143-6868 RQST
Updated Every Day 5365-01-143-6868 RQST NE Related Documents 5365-01-143-6868 1+ Documents ( More...
Restrictions 5365-01-143-6868
5365-01-143-6868 is a Ring Spacer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5365-01-143-6868
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5365-01-143-6868
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTJBHD
Approved Sources 5365-01-143-6868
- Part Number
- Manufacturer
- Status
- TT415-0147 PIECE 5
- Manufacturer
- 96169 - Electric Boat Corporation (Active)
- Primary Buy
- Primary Buy
- 518-4674751 ITEM 22
- 80064 - Naval Ship Systems Command (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5365-01-143-6868
- Characteristic
- Specifications
- FIIG
- Specifications
- A07000
- Material [MATT]
- Plastic Polyamide And Glass
- Outside Diameter [ABHE]
- 7.485 Inches Minimum And 7.487 Inches Maximum
- Inside Diameter [AARX]
- 6.513 Inches Minimum And 6.515 Inches Maximum
- Overall Thickness [ADUM]
- 0.300 Inches Nominal
- Surface Finish [CSYM]
- 63.0 Microinches Overall
Weapon Systems (WSDC) 5365-01-143-6868
DLA Procurement Analysis 5365-01-143-6868
- Last Stock Position:
- 23 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5365-01-143-6868
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-01-143-6868
Freight Information 5365-01-143-6868
5365-01-143-6868 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5365-01-143-6868 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5365-01-143-6868 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 772 for ocean manifesting and military sealift. 5365-01-143-6868 is not classified as a special type of cargo when transported by water. 5365-01-143-6868 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-01-143-6868
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5365-01-143-6868 1 Records
Contracting Technical Data File (CTDF) 5365-01-143-6868 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
