5365-01-139-1550
Machine Thread Bushing
5365011391550 011391550 845-2180765 PIECE 4 2640-670X2 PIECE 4
A straight nonfluid fitting with wrenching facilities on one end and external threads, other than pipe or hose series, on the other end. It has an unthreaded through hole in its axis which may be countersunk and/or counterbored on one or both ends. It is designed to accommodate a shaft, or the like, or used to reinforce a hole in a bulkhead, or the like. For similar items specifically designed for use in a stuffing box, see PACKING NUT. For nonfluid items with an internal thread, see INSERT, SCREW THREAD; or ADAPTER BUSHING. Excludes REDUCER, BOSS; and items designed to accommodate a tube or tube fitting. View more Machine Thread Bushing
May 2023
6
Marketplace 5365-01-139-1550
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-139-1550 5+ Documents (More...)
Photo 1/5 5365-01-139-1550 Photo 2/5 5365-01-139-1550 Photo 3/5 5365-01-139-1550 Photo 4/5 5365
BUY NE FedMall Updated Every Day 5365-01-139-1550 RQST NE Updated Every Day 5365-01-139-1550 RQST
845-2180765 PIECE 4L1 255574 PIECE 4 2640-670X2 PIECE 4 255574 PIECE 4L1 2640-670X2 PIECE 4L1
Machine Thread Bushing 5365011391550 2640-670X2 PIECE 4 A straight nonfluid fitting with wrenching
845-2180765 PIECE 4L1 255574 PIECE 4 2640-670X2 PIECE 4 255574 PIECE 4L1 2640-670X2 PIECE 4L1
2180765 PIECE 4L1255574 PIECE 42640-670X2 PIECE https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-01-139-1550
Machine Thread Bushing 5365011391550 day Upgrade your Account Upgrade 5365-01-139-1550Machine Thread
Bushing5365011391550 011391550 845-2180765 PIECE 4 845-2180765 PIECE 4L1 255574 PIECE 4 2640-670X2 PIECE
Machine Thread Bushing 5365011391550 PIECE 4 845-2180765 PIECE 4L1 255574 PIECE 4 2640-670X2 PIECE
4 255574 PIECE 4L1 2640-670X2 PIECE 4L1 PIECE 4 845-2180765 PIECE 4 2640-670X2 PIECE 4L1 845-2180765
Restrictions 5365-01-139-1550
5365-01-139-1550 is a Machine Thread Bushing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5365-01-139-1550
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
Approved Sources 5365-01-139-1550
- Part Number
- Manufacturer
- Status
- 845-2180765 PIECE 4
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
- 2640-670X2 PIECE 4
- 96169 - Electric Boat Corporation (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5365-01-139-1550
- Characteristic
- Specifications
- FIIG
- Specifications
- A540S0
- Countersink Angle In Deg [AATA]
- 60.0
- Countersink Location [BQDD]
- Threaded End
- Features Provided [CBBL]
- Countersunk
- Hole Inside Diameter [BXBR]
- 2.058 Inches Minimum And 2.068 Inches Maximum
- Material Document And Classification [MDCL]
- Qq-C-465, Alloy 632M Fed Spec Single Material Response
- Material [MATT]
- Copper Alloy
- Nominal Thread Size [CQJX]
- 4.000 Inches
- Screw Thread Length [AJYR]
- 1.000 Inches Nominal
- Overall Length [ABHP]
- 3.500 Inches Nominal
- Special Features [FEAT]
- Threaded Flange On Wrenching End,Thread Length 1.000 In. Nom,4.500-12 Un 2A Rh
- Width Across Flats [ASDB]
- 3.375 Inches Nominal
- Wrenching Facility Shape [ACSL]
- Square
- Thickness [ABNM]
- 0.656 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Series Designator [THSD]
- Un
- Thread Quantity Per Inch [CMLP]
- 8
DLA Procurement Analysis 5365-01-139-1550
Management Data 5365-01-139-1550
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-01-139-1550
Freight Information 5365-01-139-1550
5365-01-139-1550 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5365-01-139-1550 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5365-01-139-1550 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-01-139-1550 is not classified as a special type of cargo when transported by water. 5365-01-139-1550 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-01-139-1550
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5365-01-139-1550 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
