5365-01-136-5820
Machine Thread Bushing
5365011365820 011365820 7-0474-1
A straight nonfluid fitting with wrenching facilities on one end and external threads, other than pipe or hose series, on the other end. It has an unthreaded through hole in its axis which may be countersunk and/or counterbored on one or both ends. It is designed to accommodate a shaft, or the like, or used to reinforce a hole in a bulkhead, or the like. For similar items specifically designed for use in a stuffing box, see PACKING NUT. For nonfluid items with an internal thread, see INSERT, SCREW THREAD; or ADAPTER BUSHING. Excludes REDUCER, BOSS; and items designed to accommodate a tube or tube fitting. View more Machine Thread Bushing
May 2023
9
Marketplace 5365-01-136-5820
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-136-5820 1+ Documents (More...)
Every Day 5365-01-136-5820 RQST Updated Every Day 5365-01-136-5820 RQST NE Related Documents 5365-01
Thread Bushing 5365011365820 7-0474-1 A straight nonfluid fitting with wrenching facilities on one end
Restrictions 5365-01-136-5820
5365-01-136-5820 is a Machine Thread Bushing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5365-01-136-5820
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- KE
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5365-01-136-5820
- Part Number
- Manufacturer
- Status
- 7-0474-1
- Manufacturer
- 97415 - Triumph Actuation Systems - Yakima, (Active)
- Primary Buy
- Primary Buy
Datasheet 5365-01-136-5820
- Characteristic
- Specifications
- FIIG
- Specifications
- A540S0
- Countersink Angle In Deg [AATA]
- 90.0
- Countersink Depth [ADBD]
- 0.040 Inches Nominal
- Countersink Location [BQDD]
- Wrenching End
- Features Provided [CBBL]
- Countersunk
- Hole Inside Diameter [BXBR]
- 2.000 Inches Minimum And 2.005 Inches Maximum
- Material Document And Classification [MDCL]
- Qq-A-200/11, T73 Fed Spec Single Material Response
- Material [MATT]
- Aluminum Alloy 7075
- Nominal Thread Size [CQJX]
- 2.250 Inches
- Screw Thread Length [AJYR]
- 0.660 Inches Nominal
- Overall Length [ABHP]
- 0.920 Inches Nominal
- Width Across Flats [ASDB]
- 2.240 Inches Nominal
- Wrenching Facility Shape [ACSL]
- Square
- Surface Treatment Document And Classification [STDC]
- Mcdonnell Douglas Corp, P.S.13201, Type 1 Mfr Ref Single Treatment Response
- Surface Treatment [SFTT]
- Anodize
- Thickness [ABNM]
- 0.140 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Series Designator [THSD]
- Unj
- Thread Quantity Per Inch [CMLP]
- 16
DLA Procurement Analysis 5365-01-136-5820
Management Data 5365-01-136-5820
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-01-136-5820
Freight Information 5365-01-136-5820
5365-01-136-5820 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 013120. A Sub NMFC of F. It has a NMFC Description of ALUMINUM ARTICLE NOI SUB 6. 5365-01-136-5820 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05380 which rates the freight between FCL and LCL. 5365-01-136-5820 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-01-136-5820 is not classified as a special type of cargo when transported by water. 5365-01-136-5820 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-01-136-5820
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5365-01-136-5820 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
