5365-01-074-1044
Machine Thread Plug
5365010741044 010741044 4010-19
An item with a cylindrical shaped body having external threads other than pipe or hose series. It is desinged to mate into a preformed threaded component for the purpose of plugging a hole during equipment operation. It may have a head and/or internal drive and may contain a bleeder hole. See also PLUG, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL. Excludes PLUG, TUBE FITTING, THREADED. View more Machine Thread Plug
May 2023
5
Marketplace 5365-01-074-1044
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-074-1044 5+ Documents (More...)
/fsg-53/fsc-5365/us 5365-01-074-1044 Machine Thread Plug 5365010741044 https//www.nsnlookup.com /fsg
4010-19-003-7910 RQST Updated Every Day 4010-19-003-7910 RQST /fsg-53/fsc-5365/us 5365-01-074-1044 Machine
/fsg-53/fsc-5365/us 5365-01-074-1044 Machine Thread Plug 5365010741044 010741044 us 5365-01-074-1044
Machine Thread Plug 5365010741044 https//www.nsnlookup.com /fsg Every Day 4010-19-003-9703 RQST Updated
/fsg-40/fsc-4010/br 4010-19-003-7910 RQST NE Updated Every Day 4010-19-003-7910 RQST Updated Every Day
-003-7910 https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-01-074-1044 Machine Thread Plug 5365010741044
4010-19-002-2344 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-40/fsc-4010/br 4010-19-002-2344
RQST Updated Every Day 4010-19-002-2344 RQST NE Related Documents 4010-19-002-2344 5+ Documents ( More
/fsg-40/fsc-4010/br 4010-19-002-2233 Request Updated Every Day 4010-19-002-2233 RQST NE Updated Every
Day 4010-19-002-2233 RQST Updated Every Day 4010-19-002-2233 RQST NE Related Documents 4010-19-002-2233
Restrictions 5365-01-074-1044
5365-01-074-1044 is a Machine Thread Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5365-01-074-1044
- US Air Force (FXGG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- FXCX
Approved Sources 5365-01-074-1044
- Part Number
- Manufacturer
- Status
- 4010-19
- Manufacturer
- 50105 - Xar Industries Inc (Obsolete)
- Original Design
- Original Design
Datasheet 5365-01-074-1044
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Body Core Diameter [AJFC]
- 0.240 Inches Minimum And 0.245 Inches Maximum
- Bleeder Hole Center To Threaded End Distance [AJFG]
- 0.192 Inches Minimum And 0.198 Inches Maximum
- Bleeder Hole Diameter [AJFH]
- 0.060 Inches Minimum And 0.065 Inches Maximum
- Body Type [AJGE]
- Cored
- Core Depth [AJFD]
- 0.540 Inches Nominal
- Head Height [AASU]
- 0.250 Inches Nominal
- Head Type [AJGD]
- Solid
- Material Document And Classification [MDCL]
- Mil-S-7720,Cond A Mil Spec Single Material Response Overall
- Material [MATT]
- Steel Corrosion Resisting Overall
- Nominal Thread Size [CQJX]
- 0.438 Inches External
- Surface Treatment [SFTT]
- Passivate Overall
- Seat Angle [CQRB]
- 90.0 Degrees
- Overall Length [ABHP]
- 0.668 Inches Minimum And 0.672 Inches Maximum
- Special Features [FEAT]
- Seat Is Castellated
- Style Designator [STYL]
- Plug, Machine W/Bleeder Holes
- Surface Treatment Document And Classification [STDC]
- Mil-S-5002 Mil Spec Single Treatment Response Overall
- Thread Class [AAJD]
- 3A External
- Thread Direction [AAJF]
- Right-Hand External
- Thread Length [AASA]
- 0.025 Inches Minimum And 0.035 Inches Maximum External
- Thread Series Designator [THSD]
- Unf External
- Thread Quantity Per Inch [CMLP]
- 20 External
DLA Procurement Analysis 5365-01-074-1044
Management Data 5365-01-074-1044
Similar Supply Items to 5365-01-074-1044
Freight Information 5365-01-074-1044
5365-01-074-1044 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 115620. A Sub NMFC of X. It has a NMFC Description of BUSHINGS NOI I/S. 5365-01-074-1044 is rated as class 65 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 59240 which rates the freight between FCL and LCL. 5365-01-074-1044 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-01-074-1044 is not classified as a special type of cargo when transported by water. 5365-01-074-1044 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
