5365-00-924-7128
Machine Thread Plug
5365009247128 009247128 2J2864
An item with a cylindrical shaped body having external threads other than pipe or hose series. It is desinged to mate into a preformed threaded component for the purpose of plugging a hole during equipment operation. It may have a head and/or internal drive and may contain a bleeder hole. See also PLUG, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL. Excludes PLUG, TUBE FITTING, THREADED. View more Machine Thread Plug
May 2023
21
Marketplace 5365-00-924-7128
Request a Quotation from participating marketplace vendors
Related Documents 5365-00-924-7128 2+ Documents (More...)
(Identification) 1/2 NSN 5365-00-924-7128 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5365-00-924-7128 RQST Updated Every Day 5365-00-924-7128 RQST NE Related
Machine Thread Plug 5365009247128 009247128 Updated Every Day 5365-00-924-7128 RQST NE Related
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 5365-00-924-7128
Restrictions 5365-00-924-7128
5365-00-924-7128 is a Machine Thread Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5365-00-924-7128
- US Army (A919)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZ
- US Marine Corps (MC41)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC04
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- France (ZF01)
- Effective Date:
- 1 Jun 2015
- United Kingdom (ZK01)
- Effective Date:
- 1 Mar 1997
Approved Sources 5365-00-924-7128
- Part Number
- Manufacturer
- Status
- 2J2864
- Manufacturer
- 11083 - Caterpillar Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 5365-00-924-7128
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Body Core Diameter [AJFC]
- 0.062 Inches Nominal
- Bleeder Hole Center To Threaded End Distance [AJFG]
- 0.484 Inches Nominal
- Bleeder Hole Diameter [AJFH]
- 0.062 Inches Nominal
- Body Type [AJGE]
- Cored
- Connection Style [AHNC]
- Plain
- Core Depth [AJFD]
- 0.516 Inches Nominal
- Head Height [AASU]
- 0.219 Inches Nominal
- Head Diameter [AASL]
- 0.750 Inches Nominal
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 0.375 Inches External
- Seat Angle [CQRB]
- 35.0 Degrees
- Overall Length [ABHP]
- 0.781 Inches Nominal
- Special Features [FEAT]
- Seal Groove In Underside Of Head
- Style Designator [STYL]
- Plug, Machine W/Bleeder Holes
- Thread Class [AAJD]
- 2A External
- Thread Direction [AAJF]
- Right-Hand External
- Thread Length [AASA]
- 0.438 Inches Nominal External
- Thread Series Designator [THSD]
- Uns External
- Thread Quantity Per Inch [CMLP]
- 18 External
Weapon Systems (WSDC) 5365-00-924-7128
DLA Procurement Analysis 5365-00-924-7128
Management Data 5365-00-924-7128
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Feb 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5365-01-602-2752
- 0
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5365-00-924-7128
Freight Information 5365-00-924-7128
5365-00-924-7128 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093750. A Sub NMFC of Z. It has a NMFC Description of BUNGS/PLUGS NOI IN PKGS. 5365-00-924-7128 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49080 which rates the freight between FCL and LCL. 5365-00-924-7128 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 5365-00-924-7128 is not classified as a special type of cargo when transported by water. 5365-00-924-7128 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-00-924-7128
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- Vendor's Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5365-00-924-7128 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Y
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
