5365-00-350-3874
Machine Thread Plug
5365003503874 003503874 2A1146
An item with a cylindrical shaped body having external threads other than pipe or hose series. It is desinged to mate into a preformed threaded component for the purpose of plugging a hole during equipment operation. It may have a head and/or internal drive and may contain a bleeder hole. See also PLUG, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL. Excludes PLUG, TUBE FITTING, THREADED. View more Machine Thread Plug
May 2023
7
Marketplace 5365-00-350-3874
Request a Quotation from participating marketplace vendors
Related Documents 5365-00-350-3874 5+ Documents (More...)
RQST NE Updated Every Day 5365-00-350-3874 RQST Updated Every Day 5365-00-350-3874 RQST NE Related Documents
5365-00-350-3874 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-00-350-3874
www.nsnlookup.com /fsg-41/fsc-4130/uk 4130-99-538-9902 https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-00-350-3874
Machine Thread Plug 5365003503874 003503874 Upgrade for $1 a day Upgrade your Account Upgrade 5365
Restrictions 5365-00-350-3874
5365-00-350-3874 is a Machine Thread Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5365-00-350-3874
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5365-00-350-3874
- Part Number
- Manufacturer
- Status
- 2A1146
- Manufacturer
- 25472 - Goodrich Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 5365-00-350-3874
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Material [MATT]
- Copper Alloy Overall
- Style Designator [STYL]
- Plug, Machine
- Head Diameter [AASL]
- 0.758 Inches Nominal
- Head Height [AASU]
- 0.125 Inches Nominal
- Overall Length [ABHP]
- 0.450 Inches Nominal
- Connection Style [AHNC]
- Plain
- Thread Series Designator [THSD]
- Unef External
- Nominal Thread Size [CQJX]
- 0.312 Inches External
- Thread Class [AAJD]
- 2A External
- Thread Direction [AAJF]
- Right-Hand External
- Thread Length [AASA]
- 0.263 Inches Nominal External
- Head Type [AJGD]
- Solid
- Body Type [AJGE]
- Solid
- Special Features [FEAT]
- W/4.250 In.Lg Retaining Chain
Similar Supply Items to 5365-00-350-3874
Freight Information 5365-00-350-3874
5365-00-350-3874 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127220. A Sub NMFC of X. It has a NMFC Description of PRESSURE REG/RED/RELIEF VALVES NOI. 5365-00-350-3874 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64490 which rates the freight between FCL and LCL. 5365-00-350-3874 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 5365-00-350-3874 is not classified as a special type of cargo when transported by water. 5365-00-350-3874 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-00-350-3874
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
