5365-00-316-8037
Plate Spacer
5365003168037 003168037 4M49A3DM6-5
A flat metal or plastic item of various peripheral shapes having a solid (not laminated) cross-section. It is designed to maintain a predetermined distance between two surfaces. For round items without a hole having a solid rectangular cross-section use DISK, SOLID, PLAIN. For round or hexagonal items with only one hole centrally located and with the length (thickness) exceeding 25 percent of the outside diameter or distance across peripheral flats, see SPACER, SLEEVE. The thickness between the two parallel bearing surfaces must be 0.006 inch, (0.152 mm) or more for items less than 1/4 inch (6.35 mm) across the peripheral diameter, or smallest overall outside dimension, or must be 0.016 inch (0.406 mm) or more for items 1/4 inch (6.35 mm) or greater across the peripheral diameter or smallest overall outside dimension. For items with a thickness less than those indicated above, see SHIM. For items with one hole centrally located conforming to the above dimensional criteria use WASHER, FLAT or SPACER, RING as applicable. When thickness and/or outside diameter or smallest overall outside dimension is designated as a tolerance/dimension the maximum dimension will be used to determine compliance. Excludes GASKET; INSULATOR (as modified) and MOUNTING PAD, ELECTRICAL-ELECTRONIC COMPONENT. View more Plate Spacer
August 2023
4
Marketplace 5365-00-316-8037
Request a Quotation from participating marketplace vendors
Related Documents 5365-00-316-8037 5+ Documents (More...)
FedMall Updated Every Day 5365-00-316-8037 RQST NE Updated Every Day 5365-00-316-8037 RQST Updated Every
/fsg-53/fsc-5365/us 5365-00-316-8037 Plate Spacer 5365003168037003168037 Photo 1/5 5365-00-316-8037
Restrictions 5365-00-316-8037
5365-00-316-8037 is a Plate Spacer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5365-00-316-8037
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5365-00-316-8037
- US Air Force (FXGG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Supplementary Collaborators:
- KE
Approved Sources 5365-00-316-8037
- Part Number
- Manufacturer
- Status
- 4M49A3DM6-5
- Manufacturer
- 76301 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5365-00-316-8037
- Characteristic
- Specifications
- FIIG
- Specifications
- A07000
- Bolt Hole Quantity [AECS]
- 5
- Center To Center Distance Between Bolt Holes Along Length [ADUZ]
- 0.750 Inches Nominal
- Hole Diameter [AAUB]
- 0.286 Inches Minimum And 0.296 Inches Maximum
- Material Document And Classification [MDCL]
- Qq-A-250/5,T3 Fed Spec Single Material Response
- Material [MATT]
- Aluminum Alloy 2024
- Overall Length [ABHP]
- 4.420 Inches Minimum And 4.440 Inches Maximum
- Overall Width [ABMK]
- 0.406 Inches Minimum And 0.416 Inches Maximum
- Style Designator [STYL]
- Non-Circular W/Square Corners
Weapon Systems (WSDC) 5365-00-316-8037
DLA Procurement Analysis 5365-00-316-8037
Management Data 5365-00-316-8037
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-00-316-8037
Freight Information 5365-00-316-8037
5365-00-316-8037 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5365-00-316-8037 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5365-00-316-8037 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-00-316-8037 is not classified as a special type of cargo when transported by water. 5365-00-316-8037 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-00-316-8037
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any bag or sack used by the vendor
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5365-00-316-8037 5 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A618V3798
- 30 Nov 2017
- Subscribe
- 180
- Subscribe
- Subscribe
- Subscribe
- SPE4A416VD223
- 11 Jul 2016
- Subscribe
- 12
- Subscribe
- Subscribe
- Subscribe
- SPE4AL15M0199
- 15 Apr 2015
- Subscribe
- 10
- Subscribe
- Subscribe
- Subscribe
- SPE4A415M0240
- 03 Nov 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE4A015M0096
- 30 Oct 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5365-00-316-8037 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- R
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
