5365-00-068-7684
Machine Thread Plug
5365000687684 000687684 215-72407-1
An item with a cylindrical shaped body having external threads other than pipe or hose series. It is desinged to mate into a preformed threaded component for the purpose of plugging a hole during equipment operation. It may have a head and/or internal drive and may contain a bleeder hole. See also PLUG, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL. Excludes PLUG, TUBE FITTING, THREADED. View more Machine Thread Plug
May 2023
7
Marketplace 5365-00-068-7684
Request a Quotation from participating marketplace vendors
Related Documents 5365-00-068-7684 5+ Documents (More...)
Every Day 5365-00-068-7684 RQST Updated Every Day 5365-00-068-7684 RQST NE Related Documents 5365-00-
Thread Plug 5365000687684000687684 Photo 1/2 5365-00-068-7684 Photo 2/2 - - 1.
Machine Thread Plug 5365000687684 000687684 a day Upgrade your Account Upgrade 5365-00-068-7684Machine
Thread Plug5365000687684 000687684 215-72407-1 Quotation from participating marketplace vendors Request
Restrictions 5365-00-068-7684
5365-00-068-7684 is a Machine Thread Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5365-00-068-7684
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- KE
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5365-00-068-7684
- Part Number
- Manufacturer
- Status
- 215-72407-1
- Manufacturer
- 80378 - Triumph Aerostructures, Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 5365-00-068-7684
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Core Depth [AJFD]
- 0.355 Inches Minimum And 0.365 Inches Maximum
- Head Height [AASU]
- 0.100 Inches Minimum And 0.110 Inches Maximum
- Material Document And Classification [MDCL]
- Qq-S-764 Fed Spec Single Material Response Overall
- Material [MATT]
- Steel Comp 303 Overall
- Nominal Thread Size [CQJX]
- 0.375 Inches External
- Surface Treatment [SFTT]
- Passivate Overall
- Overall Length [ABHP]
- 0.545 Inches Minimum And 0.565 Inches Maximum
- Thread Class [AAJD]
- 3A External
- Thread Direction [AAJF]
- Right-Hand External
- Thread Length [AASA]
- 0.380 Inches Nominal External
- Thread Series Designator [THSD]
- Unf External
DLA Procurement Analysis 5365-00-068-7684
Management Data 5365-00-068-7684
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-00-068-7684
Freight Information 5365-00-068-7684
5365-00-068-7684 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5365-00-068-7684 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5365-00-068-7684 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-00-068-7684 is not classified as a special type of cargo when transported by water. 5365-00-068-7684 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-00-068-7684
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5365-00-068-7684 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
