5360-01-527-9479
Extension Helical Spring
5360015279479 015279479 SAE-AS13572 MS24586-C333
An open-or close-coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, so designed to provide resistance to pulling forces. The close-coiled springs may incorporate the special feature of initial tension created between the coils when wound so that an initial load must be applied to separate them. Excludes SPRING, REINFORCING, HOSE. View more Extension Helical Spring
November 2023
1
Marketplace 5360-01-527-9479
Request a Quotation from participating marketplace vendors
Related Documents 5360-01-527-9479 5+ Documents (More...)
/fsg-53/fsc-5360/us
Photo 1/4 5360-01-527-9479 Photo 2/4 5360-01-527-9479 Photo 3/4 NSN 5360-01-527-9479 (Identification
BUY NE FedMall Updated Every Day 5360-01-527-9479 RQST NE Updated Every Day 5360-01-527-9479 RQST
/fsg-99/fsc-9999/uk
/fsg-99/fsc-9999/uk
/fsg-81/fsc-8130/de
Restrictions 5360-01-527-9479
5360-01-527-9479 is a Extension Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5360-01-527-9479
- US Air Force (FGGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FGKZ
Approved Sources 5360-01-527-9479
- Part Number
- Manufacturer
- Status
- SAE-AS13572
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- MS24586-C333
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- MS24586-C333
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5360-01-527-9479
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- End Angular Relationship [AXMH]
- Ends Parallel One To Other
- Coil Quantity [APCN]
- 39.5
- End Style [ABQK]
- Short Twisted Hook First End
- Hook Radius [AXMC]
- 0.425 Inches Nominal Both Ends
- Material [MATT]
- Steel Corrosion Resisting Overall
- Inside Diameter [AARX]
- 0.850 Inches Nominal
- Load Rating [ASZD]
- 15.70 Pounds Nominal
- Spring Free Length [AGEK]
- 4.900 Inches Nominal
- Spring Free Outside Diameter [AXLQ]
- 1.000 Inches Nominal
- Stock Diameter [ACVU]
- 0.750 Inches Nominal
- Style Designator [STYL]
- Cylindrical
Weapon Systems (WSDC) 5360-01-527-9479
DLA Procurement Analysis 5360-01-527-9479
Management Data 5360-01-527-9479
Similar Supply Items to 5360-01-527-9479
Freight Information 5360-01-527-9479
5360-01-527-9479 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-01-527-9479 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-01-527-9479 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-01-527-9479 is not classified as a special type of cargo when transported by water. 5360-01-527-9479 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5360-01-527-9479 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
