5360-01-457-8029
Compression Helical Spring
5360014578029 014578029 12338316-6 RCSK18428-1B1 RCSK18428-1 456720022203
An open coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, designed to provide resistance to compression forces. Excludes springs designed for thermal actuation (springs in which the torsion forces are designed to be counteracted by changes in temperature) and SPRING, REINFORCING, HOSE. View more Compression Helical Spring
Managed by United States
NSN Created on 4 Aug 1998
Data Last Changed
October 2025
October 2025
NATO Update Count
19
19
NATO Data Quality
Marketplace 5360-01-457-8029
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5360-01-457-8029 1+ Documents (More...)
12338316-6 RCSK18428-1B1 RCSK18428-1 456720022203 An open coiled spring, wound in various forms and
Photo 1/2 NSN 5360-01-457-8029 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5360-01-457-8029 RQST Updated Every Day 5360-01-457-8029 RQST NE Related
Photo 1/2 NSN 5360-01-457-8029 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5360-01-457-8029 RQST Updated Every Day 5360-01-457-8029 RQST NE Related
Restrictions 5360-01-457-8029
5360-01-457-8029 is a Compression Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5360-01-457-8029
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5360-01-457-8029
- US Army (A919)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GT
- Croatia (WD01)
- Effective Date:
- 1 Feb 2011
- Hungary (WH01)
- Effective Date:
- 1 Nov 2011
- Slovenia (WL01)
- Effective Date:
- 1 Feb 2005
- Czech Republic (WZ01)
- Effective Date:
- 1 Apr 2010
- Canada (ZC01)
- Effective Date:
- 1 Jul 2011
- Portugal (ZP01)
- Effective Date:
- 1 Dec 2005
- Denmark (ZS01)
- Effective Date:
- 1 Sep 2009
- Greece (ZU01)
- Effective Date:
- 1 Sep 2007
- Turkey (ZW01)
- Effective Date:
- 1 Jun 2006
Approved Sources 5360-01-457-8029
- Part Number
- Manufacturer
- Status
- 12338316-6
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- RCSK18428-1B1
- 34623 - Am General Llc (Active)
- Secondary Buy
- Secondary Buy
- RCSK18428-1
- 34623 - Am General Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 456720022203
- 0000V - Ncb Hungary (Honvedsegi Egyseges (Active)
- NATO Reference
- NATO Reference
Datasheet 5360-01-457-8029
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- Coil Helix Direction [AXLH]
- Right-Hand
- Coil Quantity [APCN]
- 6-46/100
- End Style [ABQK]
- Spring End,Squared And Ground Second End
- End Style [ABQK]
- Spring End,Squared First End
- Material [MATT]
- Steel Comp 5160 Overall Or Steel Comp 5160H Overall
- Inside Diameter [AARX]
- 5.000 Inches Minimum And 5.100 Inches Maximum
- Load Rating [ASZD]
- 6510.000 Pounds Minimum And 6776.000 Pounds Maximum
- Material Document And Classification [MDCL]
- Astm A322 Assn Std 1St Material Response Overall Or Astm A304 Assn Std 2Nd Material Response Overall
- Spring Deflection Rate [AXLP]
- 1920.000 Pounds Per Inch Minimum And 2080.000 Pounds Per Inch Maximum
- Spring Free Length [AGEK]
- 12.870 Inches Nominal
- Spring Length Under Load [CSZP]
- 9.700 Inches Nominal
- Spring Solid Length [AXJQ]
- 7.190 Inches Maximum
- Style Designator [STYL]
- Cylindrical
Weapon Systems (WSDC) 5360-01-457-8029
DLA Procurement Analysis 5360-01-457-8029
- Last Stock Position:
- 1101 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5360-01-457-8029
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5360-01-457-8029
Freight Information 5360-01-457-8029
5360-01-457-8029 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-01-457-8029 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-01-457-8029 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-01-457-8029 is not classified as a special type of cargo when transported by water. 5360-01-457-8029 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5360-01-457-8029
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5360-01-457-8029 35 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L123P6687
- 11 May 2023
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE7L123P6484
- 04 May 2023
- Subscribe
- 148
- Subscribe
- Subscribe
- Subscribe
- SPE7L122P6628
- 10 Jun 2022
- Subscribe
- 301
- Subscribe
- Subscribe
- Subscribe
- SPE7L122P6642
- 10 Jun 2022
- Subscribe
- 267
- Subscribe
- Subscribe
- Subscribe
- SPE7L122P1949
- 21 Dec 2021
- Subscribe
- 52
- Subscribe
- Subscribe
- Subscribe
- SPE5EK21P0685P00003
- 03 Feb 2021
- Subscribe
- 180
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ21CF024P00004
- 25 Jan 2021
- Subscribe
- 265
- Subscribe
- Subscribe
- Subscribe
- SPE5EN19F0422
- 02 Nov 2018
- Subscribe
- 500
- Subscribe
- Subscribe
- Subscribe
- SPE5EN19F0421P00001
- 02 Nov 2018
- Subscribe
- 55
- Subscribe
- Subscribe
- Subscribe
- SPE5EN19F0423P00003
- 02 Nov 2018
- Subscribe
- 500
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F4160P00001
- 11 Jul 2018
- Subscribe
- 283
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F4005P00001
- 21 Jun 2018
- Subscribe
- 165
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F1995P00001
- 21 Mar 2018
- Subscribe
- 50
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F1994P00001
- 21 Mar 2018
- Subscribe
- 48
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F1716P00001
- 02 Mar 2018
- Subscribe
- 100
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F1369P00001
- 24 Jan 2018
- Subscribe
- 52
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0995P00001
- 29 Dec 2017
- Subscribe
- 198
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0996P00001
- 29 Dec 2017
- Subscribe
- 424
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0907
- 20 Dec 2017
- Subscribe
- 43
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0908P00001
- 20 Dec 2017
- Subscribe
- 111
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0763
- 08 Dec 2017
- Subscribe
- 63
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0579P00002
- 22 Nov 2017
- Subscribe
- 98
- Subscribe
- Subscribe
- Subscribe
- SPE5EN18F0416P00002
- 07 Nov 2017
- Subscribe
- 128
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030093
- 27 Sep 2017
- Subscribe
- 110
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030088
- 04 Sep 2017
- Subscribe
- 35
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030087
- 31 Aug 2017
- Subscribe
- 176
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030079
- 21 Jun 2017
- Subscribe
- 80
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030072
- 14 Apr 2017
- Subscribe
- 75
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D5003006801
- 17 Mar 2017
- Subscribe
- 81
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D5003006302
- 14 Feb 2017
- Subscribe
- 72
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D5003005703
- 15 Dec 2016
- Subscribe
- 65
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15D50030040
- 25 May 2016
- Subscribe
- 1000
- Subscribe
- Subscribe
- Subscribe
- SPE5EK16V3558
- 28 Apr 2016
- Subscribe
- 1000
- Subscribe
- Subscribe
- Subscribe
- SPE5EK16M0298
- 24 Nov 2015
- Subscribe
- 1500
- Subscribe
- Subscribe
- Subscribe
- SPE5EK15V3470P00002
- 17 Apr 2015
- Subscribe
- 1360
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5360-01-457-8029 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
