5360-00-846-3869
Compression Helical Spring
5360008463869 008463869 5134477 5575127 5575680
An open coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, designed to provide resistance to compression forces. Excludes springs designed for thermal actuation (springs in which the torsion forces are designed to be counteracted by changes in temperature) and SPRING, REINFORCING, HOSE. View more Compression Helical Spring
April 2025
11
Marketplace 5360-00-846-3869
Request a Quotation from participating marketplace vendors
Related Documents 5360-00-846-3869 5+ Documents (More...)
Every Day 5360-00-846-3869 RQST NE Updated Every Day 5360-00-846-3869 RQST Updated Every Day 5360-00
/fsg-53/fsc-5360/us 5360-00-846-3869 Compression Helical Spring 5360008463869 513447755751275575680
SPRING,HELICAL,COMPRESSION 10 EA NS Request Quotation Subscribe to View Vendor Details... 5575680 SPRING
,COMP 95 EA SN Request Quotation Updated Every Day 5575680 RQST NE Updated Every Day 5360-00-859-0415
SPRING 200 EA NS Request Quotation 5134477 SPRING 4 EA NS Request Quotation Subscribe to View Vendor
https//www.nsnlookup.com /fsg-53/fsc-5360/us 5360-00-846-3869 Compression Helical Spring 5360008463869
SPRING 200 EA NS Request Quotation 5134477 SPRING 4 EA NS Request Quotation Subscribe to View Vendor
Account Upgrade 5360-00-846-3869Compression Helical Spring5360008463869 008463869 5134477 ,HELICAL,COMPRESSION
how to enable JavaScript in your web browser . 1010-25-145-4836Filtermatte1010251454836 251454836 5134477
SPRING 200 EA NS Request Quotation 5134477 SPRING 4 EA NS Request Quotation Subscribe to View Vendor
Restrictions 5360-00-846-3869
5360-00-846-3869 is a Compression Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5360-00-846-3869
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2002
- Greece (ZU01)
- Effective Date:
- 1 Jul 2005
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5360-00-846-3869
- Part Number
- Manufacturer
- Status
- 5575127
- Manufacturer
- 24617 - General Motors Corp (Active)
- Primary Buy
- Primary Buy
- 5575127
- 30379 - Euclid Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5575127
- 70040 - General Motors Llc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5575680
- 30379 - Euclid Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5134477
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5360-00-846-3869
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- Coil Helix Direction [AXLH]
- Right-Hand Or Left-Hand
- Coil Quantity [APCN]
- 6
- End Style [ABQK]
- Spring End,Squared Both Ends
- Material [MATT]
- Steel Overall
- Inside Diameter [AARX]
- 0.380 Inches Minimum And 0.420 Inches Maximum
- Spring Free Length [AGEK]
- 2.330 Inches Nominal
- Spring Free Outside Diameter [AXLQ]
- 0.940 Inches Nominal
- Spring Solid Length [AXJQ]
- 0.810 Inches Nominal
- Style Designator [STYL]
- Cylindrical
DLA Procurement Analysis 5360-00-846-3869
Management Data 5360-00-846-3869
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2014
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- V
- Discontinued W/O Replacement
- V
Similar Supply Items to 5360-00-846-3869
Freight Information 5360-00-846-3869
5360-00-846-3869 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-00-846-3869 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-00-846-3869 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-00-846-3869 is not classified as a special type of cargo when transported by water. 5360-00-846-3869 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5360-00-846-3869
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Preservative Coating Only
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- No Requirement
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5360-00-846-3869 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
