5360-00-830-3882
Compression Helical Spring
5360008303882 008303882 SP7951/13 SP7951-13 7383463
An open coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, designed to provide resistance to compression forces. Excludes springs designed for thermal actuation (springs in which the torsion forces are designed to be counteracted by changes in temperature) and SPRING, REINFORCING, HOSE. View more Compression Helical Spring
July 2025
29
Marketplace 5360-00-830-3882
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5360-00-830-3882 1+ Documents (More...)
SP7951-13 SPRING,HELICAL,COMPRESSION 2 EA NS Request Quotation Subscribe to View Vendor Details... 7383463
SP7951/13 SPRING 15 EA NS Request Quotation SP7951-13 SPRING 5 EA NS Request Quotation 7383463 SPRING
Restrictions 5360-00-830-3882
5360-00-830-3882 is a Compression Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5360-00-830-3882
- US Army (A919)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5360-00-830-3882
- Part Number
- Manufacturer
- Status
- SP7951-13
- Manufacturer
- 01843 - Ambac International Corporation (Active)
- Primary Buy
- Primary Buy
- SP7951/13
- 87606 - Sullivan Bros Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- SP7951/13
- 3L018 - Southeast Power Systems Of Orlando (Active)
- Secondary Buy
- Secondary Buy
- 7383463
- 19207 - U S Army Tank Automotive Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5360008303882
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5360-00-830-3882
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- Coil Helix Direction [AXLH]
- Right-Hand
- Coil Quantity [APCN]
- 5
- End Style [ABQK]
- Spring End,Squared And Ground Both Ends
- Material [MATT]
- Steel Overall
- Inside Diameter [AARX]
- 1.178 Inches Nominal
- Load Rating [ASZD]
- 6.500 Pounds Nominal
- Spring Free Length [AGEK]
- 1.515 Inches Minimum And 1.609 Inches Maximum
- Spring Free Outside Diameter [AXLQ]
- 1.391 Inches Minimum And 1.421 Inches Maximum
- Spring Length Under Load [CSZP]
- 1.400 Inches Nominal
- Spring Solid Outside Diameter [AXJR]
- 1.391 Inches Minimum And 1.421 Inches Maximum
- Style Designator [STYL]
- Cylindrical
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5360-00-830-3882
DLA Procurement Analysis 5360-00-830-3882
Management Data 5360-00-830-3882
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
NATO Stock Numbers Related to 5360-00-830-3882
Freight Information 5360-00-830-3882
5360-00-830-3882 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-00-830-3882 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-00-830-3882 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-00-830-3882 is not classified as a special type of cargo when transported by water. 5360-00-830-3882 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5360-00-830-3882
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 5
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5360-00-830-3882 5 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE5E218V1650
- 21 Nov 2017
- Subscribe
- 28
- Subscribe
- Subscribe
- Subscribe
- SPE5E217V1755
- 16 Nov 2016
- Subscribe
- 39
- Subscribe
- Subscribe
- Subscribe
- SPE5E216V4473
- 15 Mar 2016
- Subscribe
- 15
- Subscribe
- Subscribe
- Subscribe
- SPE5E216M0287
- 18 Nov 2015
- Subscribe
- 530
- Subscribe
- Subscribe
- Subscribe
- SPE5E214V8082
- 04 Jun 2014
- Subscribe
- 42
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5360-00-830-3882 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
