5360-00-316-4273
Compression Helical Spring
5360003164273 003164273 1388637 6658950 W6680739PC36 39J873PC8 4898536 39J942PC42 W5586027PC36 W6680739SH1PC36 W6680739SH3PC36 WW5599123PC36 WW6664268PC152 WW6665747PC36 WW8453313PC8 WW8453365PC42 WW8453365SH2PC42 WW9476861PC278
An open coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, designed to provide resistance to compression forces. Excludes springs designed for thermal actuation (springs in which the torsion forces are designed to be counteracted by changes in temperature) and SPRING, REINFORCING, HOSE. View more Compression Helical Spring
November 2023
20
Marketplace 5360-00-316-4273
Request a Quotation from participating marketplace vendors
Related Documents 5360-00-316-4273 3+ Documents (More...)
WW5599123PC36 WW6664268PC152 WW6665747PC36 WW8453313PC8 WW8453365PC42 WW8453365SH2PC42 WW9476861PC278
RQST NE Updated Every Day 5360-00-316-4273 RQST Updated Every Day 5360-00-316-4273 RQST NE Related Documents
Compression Helical Spring 5360003164273 | RNVC: 1 | DAC: 5 1 Jan 1963 5360-00-316-4273 https//
www.nsnlookup.com /fsg-53/fsc-5360 Coil, Flat, Leaf, and Wire Springs from United States (US) 1963 5360-00-316-4273
/fsg-53/fsc-5360
Restrictions 5360-00-316-4273
5360-00-316-4273 is a Compression Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5360-00-316-4273
- US Navy (N9BZ)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5360-00-316-4273
- Part Number
- Manufacturer
- Status
- 1388637
- Manufacturer
- 79500 - Westinghouse Electric Corp (Active)
- Primary Buy
- Primary Buy
- 6658950
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- W6680739PC36
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 39J873PC8
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 4898536
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 39J942PC42
- 90099 - Northrop Grumman Systems Corporation (Active)
- Secondary Buy
- Secondary Buy
- 39J942PC42
- 79500 - Westinghouse Electric Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- W5586027PC36
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- W6680739SH1PC36
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- W6680739SH3PC36
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW5599123PC36
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW6664268PC152
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW6665747PC36
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW8453313PC8
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW8453365PC42
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW8453365SH2PC42
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WW9476861PC278
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- W6680739PC36
- 48521 - Colt Industries Operating Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 39J873PC8
- 11660 - Westinghouse Electric Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 39J942PC42
- 11660 - Westinghouse Electric Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5360-00-316-4273
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- Coil Helix Direction [AXLH]
- Right-Hand
- Coil Quantity [APCN]
- 10
- End Style [ABQK]
- Spring End,Ground Both Ends
- Material [MATT]
- Steel Comp 1090 Overall Or Steel Comp 1060 Overall Or Steel Comp 9260 Overall
- Inside Diameter [AARX]
- 0.2368 Inches Nominal
- Material Document And Classification [MDCL]
- Jan-S-1160,Grade 2,Type A Mil Spec All Material Responses Overall
- Spring Free Length [AGEK]
- 0.813 Inches Nominal
- Spring Deflection Rate [AXLP]
- 7.000 Pounds Per Inch Nominal
- Spring Free Outside Diameter [AXLQ]
- 0.281 Inches Minimum And 0.297 Inches Maximum
- Spring Solid Outside Diameter [AXJR]
- 0.281 Inches Minimum And 0.297 Inches Maximum
- Spring Solid Length [AXJQ]
- 0.313 Inches Nominal
- Style Designator [STYL]
- Cylindrical
- Surface Treatment [SFTT]
- Zinc Overall
DLA Procurement Analysis 5360-00-316-4273
Management Data 5360-00-316-4273
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5360-00-316-4273
Freight Information 5360-00-316-4273
5360-00-316-4273 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-00-316-4273 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-00-316-4273 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-00-316-4273 is not classified as a special type of cargo when transported by water. 5360-00-316-4273 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5360-00-316-4273
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5360-00-316-4273 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
