5360-00-131-6563
Extension Helical Spring
5360001316563 001316563 2815362
An open-or close-coiled spring, wound in various forms and from different shapes and types of materials and finished at the ends, so designed to provide resistance to pulling forces. The close-coiled springs may incorporate the special feature of initial tension created between the coils when wound so that an initial load must be applied to separate them. Excludes SPRING, REINFORCING, HOSE. View more Extension Helical Spring
May 2023
8
Marketplace 5360-00-131-6563
Request a Quotation from participating marketplace vendors
Related Documents 5360-00-131-6563 5+ Documents (More...)
/fsg-53/fsc-5360/us
5360-00-131-6563 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5360/us 5360-00-131-6563
Extension Helical Spring 5360001316563 Photo 1/2 NSN 5360-00-131-6563 (Identification) 2/2 - - 1.
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 2815362
-1 SCREW,MACHINE 51 EA NS Request Quotation Subscribe to View Vendor Details... 2815362-1 SCREW,MACHINE
/fsg-99/fsc-9999/uk
/fsg-99/fsc-9999/uk
/fsg-81/fsc-8130/de
Restrictions 5360-00-131-6563
5360-00-131-6563 is a Extension Helical Spring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5360-00-131-6563
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 2005
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5360-00-131-6563
- Part Number
- Manufacturer
- Status
- 2815362
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Original Design
- Original Design
Datasheet 5360-00-131-6563
- Characteristic
- Specifications
- FIIG
- Specifications
- A02900
- Coil Helix Direction [AXLH]
- Right-Hand Or Left-Hand
- Coil Quantity [APCN]
- 11
- Design Type [APGF]
- Closed
- End Style [ABQK]
- Machined Half Loop Both Ends
- Hook Radius [AXMC]
- 0.270 Inches Nominal Both Ends
- Material [MATT]
- Steel Overall
- Opening Width [ABPP]
- 0.156 Inches Nominal Both Ends
- Inside Diameter [AARX]
- 0.575 Inches Nominal
- Load Rating [ASZD]
- 4.00 Pounds Nominal
- Spring Deflection Rate [AXLP]
- 1.000 Pounds Per Inch Nominal
- Spring Free Length [AGEK]
- 1.349 Inches Nominal
- Spring Free Outside Diameter [AXLQ]
- 0.662 Inches Nominal
- Spring Length Under Load [CSZP]
- 1.625 Inches Nominal
- Style Designator [STYL]
- Cylindrical
- Surface Treatment [SFTT]
- Zinc Overall
Weapon Systems (WSDC) 5360-00-131-6563
DLA Procurement Analysis 5360-00-131-6563
Management Data 5360-00-131-6563
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5360-00-131-6563
Freight Information 5360-00-131-6563
5360-00-131-6563 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 177940. A Sub NMFC of X. It has a NMFC Description of SPRINGS:SPRINGS NOI. 5360-00-131-6563 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87400 which rates the freight between FCL and LCL. 5360-00-131-6563 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 579 for ocean manifesting and military sealift. 5360-00-131-6563 is not classified as a special type of cargo when transported by water. 5360-00-131-6563 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5360-00-131-6563
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- 1 inch thick
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5360-00-131-6563 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
