5355-00-168-3266
Knob
5355001683266 001683266 CPA4031-7 C321009024
An item designed to transmit manual, rotary or linear motion to other devices. May include detachable or nondetachable stud (shaft), pointer, or skirt. It may have reference markings in the form of dots, arrows, hairlines, and/or symbols which may be used in conjunction with a calibrated panel, vernier indicator, and the like to indicate the position or motion of items. For items having spokes or simulated spokes radiating from near the center to near the outside rim of the item and relatively thin round disk-shaped items 3 inches (76.2 mm) in diameter or over, see HANDWHEEL. For items calibrated in units or series of divisions to denote relative positioning of devices see DIAL, CONTROL. Excludes DOORKNOB; and HANDLE (as modified). View more Knob
May 2023
5
Marketplace 5355-00-168-3266
Request a Quotation from participating marketplace vendors
Related Documents 5355-00-168-3266 5+ Documents (More...)
/fsg-53/fsc-5355/us
Photo 1/4 NSN 5355-00-168-3266 (Identification) 2/4 NSN 5355-00-168-3266 (Identification) 3/4 NSN
BUY NE FedMall Updated Every Day 5355-00-168-3266 RQST NE Updated Every Day 5355-00-168-3266 RQST
Knob 5355001683266 001683266,CPA4031-7 -7 CPA4031-7C321009024 An item designed to transmit manual
Documents 5355-00-984-7457 1+ Documents ( More... ) https/ /www.nsnlookup.com /fsg-53/fsc-5355/us 5355-00-168-3266
Restrictions 5355-00-168-3266
5355-00-168-3266 is a Knob that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5355-00-168-3266
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5355-00-168-3266
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- KE
Approved Sources 5355-00-168-3266
- Part Number
- Manufacturer
- Status
- CPA4031-7
- Manufacturer
- 96655 - Paramount Panels, Inc. (Active)
- Primary Buy
- Primary Buy
- C321009024
- 88818 - Kearfott Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5355-00-168-3266
- Characteristic
- Specifications
- FIIG
- Specifications
- A530M0
- Distance From Hole Center To Knob/Skirt Base [ABFU]
- 0.375 Inches Nominal
- Attachment Method [ABSX]
- Setscrews
- Gripping Surface Condition [ABHG]
- Grip Aid
- Nominal Thread Size [CQJX]
- 0.164 Inches Screw Hole
- Overall Depth [ABFY]
- 0.562 Inches Nominal
- Inside Diameter [AARX]
- 0.253 Inches Minimum And 0.255 Inches Maximum
- Inside Width [ADJT]
- 0.220 Inches Minimum And 0.230 Inches Maximum
- Length [ABRY]
- 1.130 Inches Nominal
- Pointer Design [CSKT]
- Nondetachable
- Reference Marking [ABSP]
- Indicator Line
- Screw Drive Type [CBSC]
- Cross Recess Type 1
- Setscrew Hole Quantity [ABFR]
- 1
- Shaft Accommodation Style [ABHH]
- Flatted One Side
- Skirt Design [CRWX]
- Nondetachable
- Skirt Outside Diameter [CRPJ]
- 1.000 Inches Nominal
- Skirt Style [ABSL]
- Flared
- Overall Thickness [ADUM]
- 0.750 Inches Nominal
- Width [ABGL]
- 0.530 Inches Nominal
- Style Designator [STYL]
- Bar With Single Pointer
- Thread Quantity Per Inch [CMLP]
- 32 Screw Hole
- Thread Series Designator [THSD]
- Unc Screw Hole
DLA Procurement Analysis 5355-00-168-3266
Management Data 5355-00-168-3266
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5355-00-168-3266
Freight Information 5355-00-168-3266
5355-00-168-3266 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 108590. A Sub NMFC of X. It has a NMFC Description of KNOBS/PULLS DOOR/DRAWER NOI. 5355-00-168-3266 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55550 which rates the freight between FCL and LCL. 5355-00-168-3266 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5355-00-168-3266 is not classified as a special type of cargo when transported by water. 5355-00-168-3266 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
