5342-01-012-2107
Anode Retaining Plug
5342010122107 010122107 13213E5414
A metallic item similar to a standard solid pipe plug. The plug end is faced, drilled, and tapped to accommodate the threaded portion of a corrosion preventive anode. View more Anode Retaining Plug
August 2023
5
Marketplace 5342-01-012-2107
Request a Quotation from participating marketplace vendors
Related Documents 5342-01-012-2107 1+ Documents (More...)
(Identification) 1/2 NSN 5342-01-012-2107 (Identification) 2/2 - - 1.
PLUG 4 EA NS Request Quotation Updated Every Day 5342-01-012-2107 RQST NE Updated Every Day 5342-01-
Restrictions 5342-01-012-2107
5342-01-012-2107 is a Anode Retaining Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5342-01-012-2107
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5342-01-012-2107
- US Army (A919)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- A180
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5342-01-012-2107
- Part Number
- Manufacturer
- Status
- 13213E5414
- Manufacturer
- 97403 - Cecom Lr Center (Active)
- Primary Buy
- Primary Buy
Datasheet 5342-01-012-2107
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Drive End Style [AJFW]
- Hexagon
- Material Document And Classification [MDCL]
- Qq-B-626,1/2H Fed Spec Single Material Response Overall
- Material [MATT]
- Copper Alloy 360 Overall
- Nominal Thread Size [CQJX]
- 0.216 Inches Internal
- Nominal Thread Size [CQJX]
- 1.125 Inches External
- Screw Thread Series Designator [AJYP]
- Unf
- End Connection Style [AJFX]
- Unable To Decode
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand External
- Thread Direction [AAJF]
- Right-Hand Internal
- Thread Quantity Per Inch [CMLP]
- 28 Internal
- Thread Quantity Per Inch [CMLP]
- 12 External
DLA Procurement Analysis 5342-01-012-2107
Management Data 5342-01-012-2107
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5342-01-012-2107
Freight Information 5342-01-012-2107
5342-01-012-2107 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5342-01-012-2107 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5342-01-012-2107 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5342-01-012-2107 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5342-01-012-2107 is not classified as a special type of cargo when transported by water. 5342-01-012-2107 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5342-01-012-2107
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 5342-01-012-2107 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
