5342-00-857-5420
Grooved Clamp Coupling
5342008575420 008575420 99879-0737 10914625 13131-737 5340008575420
A metal loop having either a V or U cross section or channelled segment(s). It may be attached to a flat band. It is designed to create a fluid tight joint and/or connect pipe, tubing, tank cover(s), duct(s) and the like, by mating with flanged or beaded ferrule(s), flared, or beaded ends. It may or may not have a sealing inner liner. A latch or latches of the quick coupling type, nut or bolt type, or threaded trunnion type is (are) used to lock and adjust the band. Excludes COUPLING, CLAMP, PIPE and RING, LOCKING, METAL DRUM COVER. View more Grooved Clamp Coupling
August 2025
31
Marketplace 5342-00-857-5420
Request a Quotation from participating marketplace vendors
Related Documents 5342-00-857-5420 5+ Documents (More...)
Photo 1/3 NSN 5342-00-857-5420 (Identification) 2/3 NSN 5342-00-857-5420 (Identification) 3/3 -
5342-00-857-5420 RQST Updated Every Day 5342-00-857-5420 RQST NE Related Documents 5342-00-857-5420
https//www.nsnlookup.com /fsg-53/fsc-5342/tr 5342-27-015-0257 Grooved Clamp Coupling 5342270150257 10914625
Grooved Clamp Coupling 5342008575420 Upgrade your Account Upgrade 5342-00-857-5420Grooved Clamp
Restrictions 5342-00-857-5420
5342-00-857-5420 is a Grooved Clamp Coupling that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5342-00-857-5420
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5342-00-857-5420
- US Army (A919)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZBF
- US Marine Corps (MC41)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Jan 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1996
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Jul 2003
Approved Sources 5342-00-857-5420
- Part Number
- Manufacturer
- Status
- 99879-0737
- Manufacturer
- 54646 - Clampco Products, Inc. (Active)
- Primary Buy
- Primary Buy
- 10914625
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 13131-737
- 54646 - Clampco Products, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5340008575420
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 13131-737
- 00671 - Specialty Products Co Div Of Clampco (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5342-00-857-5420
- Characteristic
- Specifications
- FIIG
- Specifications
- A25400
- Cross-Sectional Shape Style [AAGR]
- Grooved Retainer
- Retainer Thickness [ADTJ]
- 0.080 Inches Nominal
- Retainer Width [ALEB]
- 0.750 Inches Nominal
- Root Width [ALEC]
- 0.181 Inches Nominal
- Band Thickness [ALED]
- 0.040 Inches Nominal
- Band Width [ALEE]
- 1.000 Inches Nominal
- Height [HGTH]
- 0.281 Inches Nominal
- Included Angle In Deg [AKZZ]
- 40.0
- Material And Location [ANNQ]
- Steel Band
- Material And Location [ANNQ]
- Steel Segment
- Material And Location [ANNQ]
- Steel, Corrosion Resisting Bolt
- Material And Location [ANNQ]
- Steel, Corrosion Resisting Nut
- Shape [SHPE]
- Round
- Inside Diameter [AARX]
- 7.375 Inches Nominal
- Latch Style [AGPR]
- Single
- Nut Type [ALDS]
- Self-Locking Hexagon
- Segment Quantity [ALDT]
- 2
- Sealing Inner Liner [ALDW]
- Not Included
Weapon Systems (WSDC) 5342-00-857-5420
DLA Procurement Analysis 5342-00-857-5420
- Last Stock Position:
- 150 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5342-00-857-5420
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- K
- Reserved
- Operational Test:
- No Special Procedures
Similar Supply Items to 5342-00-857-5420
Freight Information 5342-00-857-5420
5342-00-857-5420 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5342-00-857-5420 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5342-00-857-5420 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5342-00-857-5420 is not classified as a special type of cargo when transported by water. 5342-00-857-5420 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5342-00-857-5420
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
