5342-00-679-8008
Protection Bellows
5342006798008 006798008 10863009 170-69 2530006798008
A nonmetallic, accordian shaped protective covering designed to flex due to relative motion between parts to which its opposite ends are attached. It is primarily used to cover the opening around a movable push-pull rod or part passing through a hole in a bulkhead, partition or the like. View more Protection Bellows
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
July 2025
July 2025
NATO Update Count
42
42
NATO Data Quality
Marketplace 5342-00-679-8008
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5342-00-679-8008 3+ Documents (More...)
10863009 170-69 2530006798008 A nonmetallic, accordian shaped protective covering designed to flex due
United States (US) 4. 5342-00-679-8008 Marketplace Restrictions Approved Sources Datasheet Management
Day 5342-00-679-8008 RQST Updated Every Day 5342-00-679-8008 RQST NE Related Documents 5342-00-679-8008
United States (US) 4. 5342-00-679-8008 Marketplace Restrictions Approved Sources Datasheet Management
Day 5342-00-679-8008 RQST Updated Every Day 5342-00-679-8008 RQST NE Related Documents 5342-00-679-8008
enable JavaScript in your web browser . 1680-99-365-4551Head Assembly Cable1680993654551 993654551 10863009
Protection Bellows 5342006798008 006798008 $1 a day Upgrade your Account Upgrade 5342-00-679-8008Protection
Bellows5342006798008 006798008 10863009 006798008.2530 BELLOWS,PROTECTION 509 EA NS Request Quotation
Protection Bellows 5342006798008 006798008 $1 a day Upgrade your Account Upgrade 5342-00-679-8008Protection
Bellows5342006798008 006798008 10863009 006798008.2530 BELLOWS,PROTECTION 509 EA NS Request Quotation
JavaScript in your web browser . 4910-27-019-9698Tire Vulcanizing Mold4910270199698 270199698 2530006798008
Specialized Equipment from Turkey (TR) 4910-27-019-9698 https//www.nsnlookup.com /fsg-53/fsc-5342/us 5342-00-679-8008
Protection Bellows 5342006798008 006798008 BELLOWS,PROTECTION 509 EA NS Request Quotation https
Specialized Equipment from Turkey (TR) 4910-27-019-9698 https//www.nsnlookup.com /fsg-53/fsc-5342/us 5342-00-679-8008
Protection Bellows 5342006798008 006798008 BELLOWS,PROTECTION 509 EA NS Request Quotation https
Restrictions 5342-00-679-8008
5342-00-679-8008 is a Protection Bellows that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5342-00-679-8008
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5342-00-679-8008
- US Army (A919)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZBD
- US Air Force (FXGG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Lithuania (WI01)
- Effective Date:
- 1 Mar 2001
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 May 2006
- Turkey (ZW01)
- Effective Date:
- 1 Jan 2003
Approved Sources 5342-00-679-8008
- Part Number
- Manufacturer
- Status
- 10863009
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 170-69
- 92865 - Zf Off-Highway Solutions Minnesota (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2530006798008
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 10863009
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 5342-00-679-8008
- Characteristic
- Specifications
- FIIG
- Specifications
- A539Z0
- Fsc Application Data [ZZZV]
- Rivot Brake,Master Cylinder
- Material Document And Classification [MDCL]
- Mil-R-3065, Type S, Class Sb, Grade 410Abf1g Mil Spec Single Material Response Or Mil-R-3065, Type S, Class 3B, Grade 415Abf1g Mil Spec Single Material Response
- Material [MATT]
- Rubber Synthetic
- Neutral Length [CPYN]
- 2.000 Inches Nominal
- Large End Inside Diameter [CDDB]
- 1.156 Inches Nominal
- Large End Inside Length [CPYM]
- 0.125 Inches Nominal
- Large End Outside Diameter [AHMG]
- 1.250 Inches Nominal
- Large End Outside Length [CPYS]
- 0.125 Inches Nominal
- Small End Inside Diameter [CDDD]
- 0.438 Inches Nominal
- Small End Inside Length [CPYT]
- 0.188 Inches Nominal
- Small End Outside Diameter [AHMH]
- 0.625 Inches Nominal
- Small End Outside Length [CPYF]
- 0.188 Inches Nominal
- Special Features [FEAT]
- Synthetic Rubber Material Is Nbr Nitrile Per Astm D2000
- Thickness [ABNM]
- 0.094 Inches Nominal
Weapon Systems (WSDC) 5342-00-679-8008
DLA Procurement Analysis 5342-00-679-8008
Management Data 5342-00-679-8008
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5342-00-679-8008
9390-27-053-4709 5342-12-358-7663 9390-12-310-3315 9390-12-306-4158 9390-27-034-1532 5340-43-001-1179 9390-12-317-4819 5340-99-605-4092 9390-21-908-5129 5342-12-349-8739 5340-99-200-0128 9390-12-300-5828 9390-26-301-1280 9390-12-159-8628 5340-12-330-2573 5340-27-022-7397 5340-99-477-3484 5340-27-032-9810
Freight Information 5342-00-679-8008
5342-00-679-8008 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 156600. A Sub NMFC of Z. It has a NMFC Description of PLASTIC/RUBBER ARTICLE VIZ:. 5342-00-679-8008 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5342-00-679-8008 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 77670 which rates the freight between FCL and LCL. 5342-00-679-8008 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 772 for ocean manifesting and military sealift. 5342-00-679-8008 is not classified as a special type of cargo when transported by water. 5342-00-679-8008 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5342-00-679-8008
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 2.0" H x 1.7" W x 1.7" L
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 2.6" H x 2.0" W x 2.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 2.6" H x 2.0" W x 2.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- Type I, shelf life
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 5342-00-679-8008 1 Records
Contracting Technical Data File (CTDF) 5342-00-679-8008 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
