5342-00-678-6178
Grooved Clamp Coupling
5342006786178 006786178 U4301S3 50097C584 8711310 5340006786178 N50097C584 U4301S3-584 50097-584
A metal loop having either a V or U cross section or channelled segment(s). It may be attached to a flat band. It is designed to create a fluid tight joint and/or connect pipe, tubing, tank cover(s), duct(s) and the like, by mating with flanged or beaded ferrule(s), flared, or beaded ends. It may or may not have a sealing inner liner. A latch or latches of the quick coupling type, nut or bolt type, or threaded trunnion type is (are) used to lock and adjust the band. Excludes COUPLING, CLAMP, PIPE and RING, LOCKING, METAL DRUM COVER. View more Grooved Clamp Coupling
May 2025
31
Marketplace 5342-00-678-6178
Request a Quotation from participating marketplace vendors
Related Documents 5342-00-678-6178 1+ Documents (More...)
-00-678-6178 Grooved Clamp Coupling 5342006786178,U4301S3 U4301S350097C58487113105340006786178N50097C584U4301S3
Day 5342-00-678-6178 RQST NE Related -00-678-6178 Grooved Clamp Coupling 5342006786178,U4301S3 U4301S350097C58487113105340006786178N50097C584U4301S3
Restrictions 5342-00-678-6178
5342-00-678-6178 is a Grooved Clamp Coupling that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5342-00-678-6178
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5342-00-678-6178
- US Army (A919)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZ
- US Air Force (FXGG)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- FXCX
- US Marine Corps (MC41)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5342-00-678-6178
- Part Number
- Manufacturer
- Status
- U4301S3
- Manufacturer
- 94581 - V I J Corp (Active)
- Primary Buy
- Primary Buy
- 50097C584
- 00624 - Eaton Aeroquip Llc (Active)
- Secondary Buy
- Secondary Buy
- 5340006786178
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- N50097C584
- 00624 - Eaton Aeroquip Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- U4301S3-584
- 94581 - V I J Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 50097-584
- 00624 - Eaton Aeroquip Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8711310
- 19207 - U S Army Tank Automotive Command (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5342-00-678-6178
- Characteristic
- Specifications
- FIIG
- Specifications
- A25400
- Cross-Sectional Shape Style [AAGR]
- Grooved Retainer
- Retainer Thickness [ADTJ]
- 0.047 Inches Nominal
- Retainer Width [ALEB]
- 0.720 Inches Nominal
- Root Width [ALEC]
- 0.212 Inches Nominal
- Band Thickness [ALED]
- 0.025 Inches Nominal
- Band Width [ALEE]
- 0.750 Inches Nominal
- Height [HGTH]
- 0.281 Inches Nominal
- Included Angle In Deg [AKZZ]
- 40.0
- Material And Location [ANNQ]
- Steel Overall
- Shape [SHPE]
- Round
- Inside Diameter [AARX]
- 5.845 Inches Nominal
- Latch Style [AGPR]
- Single
- Nut Type [ALDS]
- Self-Locking Hexagon
- Segment Quantity [ALDT]
- 3
- Sealing Inner Liner [ALDW]
- Not Included
Weapon Systems (WSDC) 5342-00-678-6178
DLA Procurement Analysis 5342-00-678-6178
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5342-00-678-6178
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
NATO Stock Numbers Related to 5342-00-678-6178
Freight Information 5342-00-678-6178
5342-00-678-6178 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 105200. A Sub NMFC of X. It has a NMFC Description of FITTINGS CABLE/CHAIN/ROPE I/S. 5342-00-678-6178 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 54160 which rates the freight between FCL and LCL. 5342-00-678-6178 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5342-00-678-6178 is not classified as a special type of cargo when transported by water. 5342-00-678-6178 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5342-00-678-6178
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 5342-00-678-6178 7 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623FC1W8
- 19 Sep 2023
- Subscribe
- 69
- Subscribe
- Subscribe
- Subscribe
- SPE4A623FC1W8
- 19 Sep 2023
- Subscribe
- 69
- Subscribe
- Subscribe
- Subscribe
- SPE4A723V2246
- 02 May 2023
- Subscribe
- 95
- Subscribe
- Subscribe
- Subscribe
- SPE4A723P9724
- 30 Apr 2023
- Subscribe
- 34
- Subscribe
- Subscribe
- Subscribe
- SPE4A617P6723
- 31 Jan 2017
- Subscribe
- 204
- Subscribe
- Subscribe
- Subscribe
- SPE4A616M7753
- 09 Feb 2016
- Subscribe
- 492
- Subscribe
- Subscribe
- Subscribe
- SPE4A414V6622
- 14 Jan 2014
- Subscribe
- 236
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5342-00-678-6178 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
