5342-00-244-2600
Grooved Clamp Coupling
5342002442600 002442600 11241363-3 STYLE78-1-1-2INGRT
A metal loop having either a V or U cross section or channelled segment(s). It may be attached to a flat band. It is designed to create a fluid tight joint and/or connect pipe, tubing, tank cover(s), duct(s) and the like, by mating with flanged or beaded ferrule(s), flared, or beaded ends. It may or may not have a sealing inner liner. A latch or latches of the quick coupling type, nut or bolt type, or threaded trunnion type is (are) used to lock and adjust the band. Excludes COUPLING, CLAMP, PIPE and RING, LOCKING, METAL DRUM COVER. View more Grooved Clamp Coupling
June 2023
5
Marketplace 5342-00-244-2600
Request a Quotation from participating marketplace vendors
Related Documents 5342-00-244-2600 2+ Documents (More...)
BUY NE FedMall Updated Every Day 5342-00-244-2600 RQST NE Updated Every Day 5342-00-244-2600 RQST
Updated Every Day 5342-00-244-2600 RQST NE Related Documents 5342-00-244-2600 2+ Documents ( More...
Grooved Clamp Coupling 5342002442600 RQST NE Updated Every Day 5342-00-244-2600 RQST https//www.nsnlookup.com
Restrictions 5342-00-244-2600
5342-00-244-2600 is a Grooved Clamp Coupling that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5342-00-244-2600
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5342-00-244-2600
- US Army (A919)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- A180
- US Air Force (FXGG)
- Effective Date:
- 1 May 2005
Approved Sources 5342-00-244-2600
- Part Number
- Manufacturer
- Status
- 11241363-3
- Manufacturer
- 17773 - Ballistic Missile Defense Systems (Active)
- Primary Buy
- Primary Buy
- STYLE78-1-1-2INGRT
- 79154 - Victaulic Company Of America Inc (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5342-00-244-2600
- Characteristic
- Specifications
- FIIG
- Specifications
- A25400
- Drilled Lockwire Hole [ASXG]
- Included
- Cross-Sectional Shape Style [AAGR]
- Grooved Retainer
- Maximum Load Rating [AGCS]
- 500.0 Pounds
- Inside Diameter [AARX]
- 1.500 Inches Nominal
- Latch Style [AGPR]
- Single
- Material And Location [ANNQ]
- Steel Overall
- Sealing Inner Liner [ALDW]
- Included
- Segment Quantity [ALDT]
- 2
- Shape [SHPE]
- Round
- Surface Treatment And Location [ANNR]
- Cadmium, Qq-P-416, Type 2, Class 1 Overall
- Temp Rating [ABJH]
- 250.0 Deg Fahrenheit
