5340-01-520-7262
Friction Catch
5340015207262 015207262 BACC12C4
A nonpositive fastening device consisting of (1) a SPRING ACTUATED BALL, BOLT, PLUNGER, DOUBLE BEVEL LATCH, or the like, which is designed to be inserted and retained by compression of the spring, in a recess or STRIKE, CATCH. It may include the STRIKE, CATCH or (2) a two piece item consisting of a STUD, FRICTION CATCH and a RECEPTACLE, FRICTION CATCH STUD. The items are designed to position a door, cover, panel, or the like, in a fixed position and are released by normal pull. The items do not have provisions such as a knob, handle, or lever to actuate the bolt or plunger. Excludes CATCH MAGNETIC. View more Friction Catch
January 2023
2
Marketplace 5340-01-520-7262
Request a Quotation from participating marketplace vendors
Related Documents 5340-01-520-7262 1+ Documents (More...)
/fsg-53/fsc-5340/us
Every Day 5340-01-520-7262 RQST Updated Every Day 5340-01-520-7262 RQST NE Related Documents 5340-01-
Sources Datasheet Management BACC12C4 CATCH,FRICTION 2 EA NS Request Quotation Updated Every Day 5340
Restrictions 5340-01-520-7262
5340-01-520-7262 is a Friction Catch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5340-01-520-7262
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-01-520-7262
- New Zealand (ZE01)
- Effective Date:
- 1 May 2004
Approved Sources 5340-01-520-7262
- Part Number
- Manufacturer
- Status
- BACC12C4
- Manufacturer
- 81205 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-01-520-7262
- Characteristic
- Specifications
- FIIG
- Specifications
- A10600
- Material [MATT]
- Copper Alloy Case
- Surface Treatment [SFTT]
- Nickel Strike
- Style Designator [STYL]
- Pressure
- Part Name Assigned By Controlling Agency [CXCY]
- Catch, Friction-Ball, Wood Mounted
NATO Stock Numbers Related to 5340-01-520-7262
Freight Information 5340-01-520-7262
5340-01-520-7262 has freight characteristics managed by New Zealand.. 5340-01-520-7262 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
