5340-01-380-8553
Double Angle Bracket
5340013808553 013808553 4078180-01
A rigid item usually fabricated from flat material, forming two alternate or two adjacent interior angles, both which are less than 180 degrees (3.141 radians). It is designed to position, align, and/or support an item. It may be reinforced. See also BRACKET, ANGLE and BRACKET (1), MOUNTING. View more Double Angle Bracket
June 2023
17
Marketplace 5340-01-380-8553
Request a Quotation from participating marketplace vendors
Related Documents 5340-01-380-8553 5+ Documents (More...)
Photo 1/4 5340-01-380-8553 Photo 2/4 NSN 5340-01-380-8553 (Identification) 3/4 NSN 5340-01-380-
BRACKET,DOUBLE ANGLE RQST NS Request Quotation Updated Every Day 5340-01-380-8553 RQST NE Updated
Restrictions 5340-01-380-8553
5340-01-380-8553 is a Double Angle Bracket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5340-01-380-8553
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2007
- Former MOE Rule:
- FXX5
- Israel (YD01)
- Effective Date:
- 1 Oct 2016
- Singapore (YJ01)
- Effective Date:
- 1 Oct 1997
- Belgium (ZB01)
- Effective Date:
- 1 Oct 1997
- Republic of Korea (ZH01)
- Effective Date:
- 1 Mar 1997
- Netherlands (ZN01)
- Effective Date:
- 1 Oct 1995
- Denmark (ZS01)
- Effective Date:
- 1 May 1994
- Norway (ZT01)
- Effective Date:
- 1 Jul 1994
Approved Sources 5340-01-380-8553
- Part Number
- Manufacturer
- Status
- 4078180-01
- Manufacturer
- 77445 - Rtx Corporation (Active)
- Primary Buy
- Primary Buy
- 4078180-01
- 52661 - Rtx Corporation (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5340-01-380-8553
- Characteristic
- Specifications
- FIIG
- Specifications
- A042A0
- End Item Identification [AGAV]
- Fpw100/200/220/220E
- First Leg Distance From Edge To Hole Center Along Width [AHRA]
- 0.297 Inches Nominal
- First Leg Hole Arrangement Style [AKAU]
- One Slot
- First Leg Slot Length [AHLL]
- 0.493 Inches Minimum And 0.513 Inches Maximum
- First Leg Slot Width [AHLM]
- 0.198 Inches Minimum And 0.208 Inches Maximum
- Material [MATT]
- Nickel Alloy
- Mounting Hole Type [ACHY]
- Plain
- Material Document And Classification [MDCL]
- Ams5599 Assn Std Single Material Response
- Second Leg Distance Between Hole Centers Along Length [AHLS]
- 1.165 Nominal Inches
- Second Leg Hole Arrangement Style [AKCU]
- Two Holes
- Second Leg Hole Diameter [AHLN]
- 0.276 Inches Minimum And 0.286 Inches Maximum
- Second Leg Relationship To First Leg [CSSP]
- Not Identical
- Special Features [FEAT]
- Contains 2 Spacers, P/N 4078184
