5340-01-284-8284
Clamping Catch
5340012848284 012848284 102917
A positive fastening device consisting of a mountable base with an extended loop, claw, or the like. It may include a catch strike and mounting hardware for its complete installation on flat surfaces. The loop, claw, or the like can be manually engaged or disengaged readily for the purpose of securing the mating sections of a suitcase, locker-trunk, shipping and storage container, prefabricated building, tool chest or the like. Excludes CATCH, ELBOW; CATCH, FLUSH; CATCH, FRICTION; and LATCH or LOCK (as modified). View more Clamping Catch
November 2023
6
Marketplace 5340-01-284-8284
Request a Quotation from participating marketplace vendors
Related Documents 5340-01-284-8284 5+ Documents (More...)
/fsg-53/fsc-5340/us
United States (US) 4. 5340-01-284-8284 Marketplace Restrictions Approved Sources Datasheet Management
CATCH,CLAMPING 141 EA NS Request Quotation Updated Every Day 5340-01-284-8284 RQST NE Updated Every
5365-27-051-4193 Shim 5365270514193 270514193,102917 7731Electrical Contact5999014867731 014867731 1-102917
LHNAR50350 JavaScript in your web browser . 5905-99-436-1966Resistor5905994361966 994361966LHNAR503500632-102917
Shim 5365270514193 270514193,102917 Request https//www.nsnlookup.com /fsg-53/fsc-5340/us 5340-01-284-8284
Clamping Catch 5340012848284 012848284 https/ Upgrade for $1 a day Upgrade your Account Upgrade
a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 1-102917
$1 a day Upgrade your Account Upgrade 5999-01-486-7731Electrical Contact5999014867731 0148677311-102917
Shim 5365270514193 270514193,102917 Request Subscribe to View Vendor Details... 1-102917 https/ Upgrade
for $1 a day Upgrade your Account Upgrade 5950-00-853-7932Transformer5950008537932 008537932 102917
Restrictions 5340-01-284-8284
5340-01-284-8284 is a Clamping Catch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5340-01-284-8284
- US Army (A919)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CL
- US Air Force (FXGI)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Spain (YB01)
- Effective Date:
- 1 Apr 2013
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 1995
- Greece (ZU01)
- Effective Date:
- 1 Jun 2006
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Mar 2003
Approved Sources 5340-01-284-8284
- Part Number
- Manufacturer
- Status
- 102917
- Manufacturer
- 29724 - Thermodyne International, Ltd (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-01-284-8284
- Characteristic
- Specifications
- FIIG
- Specifications
- A03100
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Style Designator [STYL]
- Special
- Engaging Surface Width [CJMH]
- 0.945 Inches Nominal
- Hole Quantity [ASXK]
- 2
- Overall Length [ABXG]
- 2.810 Inches Nominal
- Overall Width [ABHC]
- 2.240 Inches Nominal
- Overall Height [CTHX]
- 0.365 Inches Nominal
- Design Type [APGF]
- Claw Engaging
- Operation Method [APHE]
- Lever
Weapon Systems (WSDC) 5340-01-284-8284
DLA Procurement Analysis 5340-01-284-8284
- Last Stock Position:
- 49 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5340-01-284-8284
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5340-01-284-8284
Freight Information 5340-01-284-8284
5340-01-284-8284 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093880. A Sub NMFC of X. It has a NMFC Description of CATCHES/LATCHES METAL NOI. 5340-01-284-8284 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49120 which rates the freight between FCL and LCL. 5340-01-284-8284 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-01-284-8284 is not classified as a special type of cargo when transported by water. 5340-01-284-8284 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-01-284-8284
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5340-01-284-8284 6 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE5EM17V2679
- 03 Feb 2017
- Subscribe
- 190
- Subscribe
- Subscribe
- Subscribe
- SPE5EM16V7479
- 02 Sep 2016
- Subscribe
- 209
- Subscribe
- Subscribe
- Subscribe
- SPE5EM16V2541
- 12 Feb 2016
- Subscribe
- 196
- Subscribe
- Subscribe
- Subscribe
- SPE5EM15V3803
- 06 Apr 2015
- Subscribe
- 59
- Subscribe
- Subscribe
- Subscribe
- SPE5E414V5515
- 10 Mar 2014
- Subscribe
- 123
- Subscribe
- Subscribe
- Subscribe
- SPE5E813M0050
- 24 Sep 2013
- Subscribe
- 145
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5340-01-284-8284 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
