5340-01-127-9550
Rod End Connector
5340011279550 011279550 4197015-2
An item which has one end designed to form a rigid connection on a rod, shaft, turnbuckle or the like by means of welding, threading and/or pinning. The opposite end provides a hinged or semirigid method of fastening or attaching to another part by means of a protruding tongue or block. May include provisions for locking. See also CLEVIS, ROD END and ROD END, THREADED. For items specifically designed for aviation, see CONNECTOR, ROD END, AVIATION. View more Rod End Connector
July 2025
12
Marketplace 5340-01-127-9550
Request a Quotation from participating marketplace vendors
Related Documents 5340-01-127-9550 1+ Documents (More...)
5340-01-127-9550 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5340/us 5340-01-127-9550
Day 5340-01-127-9550 RQST NE Related Documents 5340-01-127-9550 1+ Documents ( More... ) https//www.nsnlookup.com
Restrictions 5340-01-127-9550
5340-01-127-9550 is a Rod End Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5340-01-127-9550
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Feb 1997
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 5340-01-127-9550
- Part Number
- Manufacturer
- Status
- 4197015-2
- Manufacturer
- 80212 - Bae Systems Land & Armaments L.P. (Active)
- Primary Buy
- Primary Buy
- 4197015-2
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 5340-01-127-9550
- Characteristic
- Specifications
- FIIG
- Specifications
- A264A0
- Distance From End To Hole Center [BFKT]
- 4.750 Inches Nominal
- Material Document And Classification [MDCL]
- Mil-S-46172 Mil Spec All Material Responses Overall
- Nominal Thread Size [CQJX]
- 0.500 Inches Rod Connection
- Material [MATT]
- Steel Comp 1010 Or Steel Comp 1011 Or Steel Comp 1012 Or Steel Comp 1013 Or Steel Comp 1016 Or Steel Comp 1017 Or Steel Comp 1018 Or Steel Comp 1019 Or Steel Comp 1020 Or Steel Comp 1021 Or Steel Comp 1022 Or Steel Comp 1023 Or Steel Comp 1025 Overall
- Shank Overall Length [ATCG]
- 3.500 Inches Nominal
- Tongue Width [AHHE]
- 0.938 Inches Nominal
- Tongue Thickness [AHHF]
- 0.562 Inches Nominal
- Style Designator [STYL]
- Connector
- Thread Class [AAJD]
- 2A Rod Connection
- Thread Direction [AAJF]
- Left-Hand Rod Connection
- Thread Length [AASA]
- 3.500 Inches Nominal Rod Connection
- Thread Series Designator [THSD]
- Unf Rod Connection
Similar Supply Items to 5340-01-127-9550
Freight Information 5340-01-127-9550
5340-01-127-9550 has freight characteristics managed by the Netherlands.. 5340-01-127-9550 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
