5340-01-009-4976
Retaining Strap
5340010094976 010094976 1531600
A preformed item of rigid or semirigid material designed to partially surround other items such as cable(s), conduit(s), pipe(s), tube(s), or rod(s) or to completely surround them by means of a bridge strap(s) (which does not tightly clamp against the complete periphery). It is designed to retain and/or position the items close to a structure. It may be fastened to the structure on one end, both ends, or in the center. See also CLAMP, LOOP. Excludes BRACKET, PIPE; STRAP, LEATHER and STRAP, WEBBING. View more Retaining Strap
May 2023
20
Marketplace 5340-01-009-4976
Request a Quotation from participating marketplace vendors
Related Documents 5340-01-009-4976 5+ Documents (More...)
5340-01-009-4976 Photo 5/21 5340-01-009-4976 Photo 6/21 5340-01-009-4976 Photo 7/21 5340-01-009-4976
Photo 8/21 5340-01-009-4976 Photo 9/21 5340-01-009-4976 Photo 10/21 5340-01-009-4976 Photo 11/21 5340
Retaining Strap 5340010094976 010094976 for $1 a day Upgrade your Account Upgrade 5340-01-009-4976Retaining
Strap5340010094976 010094976 1531600 JavaScript in your web browser . 5360-99-800-8499Compression Helical
Retaining Strap 5340010094976 010094976 for $1 a day Upgrade your Account Upgrade 5340-01-009-4976Retaining
Strap5340010094976 010094976 1531600 Pad Eye 5340121932535 121932535,1531600 G-1531600 A rigid, metal
Restrictions 5340-01-009-4976
5340-01-009-4976 is a Retaining Strap that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5340-01-009-4976
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-01-009-4976
- Part Number
- Manufacturer
- Status
- 1531600
- Manufacturer
- 64547 - Honeywell International, Inc (Active)
- Primary Buy
- Primary Buy
- 1531600
- 83298 - Allied Signal Inc (Replaced)
- Original Design
- Original Design
Datasheet 5340-01-009-4976
- Characteristic
- Specifications
- FIIG
- Specifications
- T372-A
- Center To Center Distance Between Arch And Mounting Hole [BYMR]
- 0.249 Inches Minimum And 0.254 Inches Maximum
- Cushion [BXQG]
- Not Included
- Material Thickness [ABPX]
- 0.015 Inches Nominal
- Material [MATT]
- Steel
- Mounting Hole Size [BYML]
- 0.257 Inches Minimum And 0.262 Inches Maximum
- Mounting Pad [BXQJ]
- Not Included
- Inside Diameter/Arch Length [BYMP]
- 0.468 Inches Minimum And 0.469 Inches Maximum
- Overall Length [ABHP]
- 0.472 Inches Minimum And 0.487 Inches Maximum
- Overall Width [ABMK]
- 0.368 Inches Minimum And 0.378 Inches Maximum
- Style Designator [STYL]
- U
- Surface Treatment [SFTT]
- Cadmium
Similar Supply Items to 5340-01-009-4976
Freight Information 5340-01-009-4976
5340-01-009-4976 has freight characteristics managed by the Defense Intelligence Agency (DIA).. 5340-01-009-4976 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
