5340-00-971-7777
Butt Hinge
5340009717777 009717777 BHMA-A156.1 F191US3 4 1/2X4 1/2 F-191-4 1/2X4 1/2-US10 191 ANAI A 156.1-1981 TYPE A2133
A hinge usually with rectangularly shaped leaves. The dimension parallel to the hinge pin must be greater than the dimension transverse to the hinge pin. It may have a tension coil spring at its pivot(s) for closing action, and may have a third member between its pivot(s) to permit the door, or the like, to swing in an arc from either side. View more Butt Hinge
November 2023
3
Marketplace 5340-00-971-7777
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-971-7777 5+ Documents (More...)
ANAI A 156.1-1981 TYPE A2133 HINGE 40 EA NS Request Quotation Subscribe to View Vendor Details... 191
View Vendor Details... 191 HINGE,BUTT RQST NS Request Quotation FedMall Updated Every 15 Minutes 5340
A8133 BHMA-A156.1 A8133 3-1/2IN ANSI A156.1 A8133 FFH116 ANSI A156.1 A8133 80204 A8133 BHMA-A156.1 A8133
A8133 3-1/2IN ANSI - American National A8133 BHMA-A156.1 A8133 3-1/2IN ANSI A156.1 A8133 FFH116 ANSI
A8133 BHMA-A156.1 A8133 3-1/2IN ANSI A156.1 A8133 FFH116 ANSI American National A8133 BHMA-A156.1 A8133
A8133 3-1/2IN ANSI A156.1 A8133 FFH116 A8133 80204 - American National A8133 BHMA-A156.1 A8133 3-1/2IN
A8133 3-1/2IN ANSI A156.1 A8133 FFH116 A8133 80204 - American National A8133 BHMA-A156.1 A8133 80204
A8133 BHMA-A156.1 A8133 3-1/2IN ANSI A156.1 A8133 FFH116 ANSI A156.1 A8133 80204 - American National
Restrictions 5340-00-971-7777
5340-00-971-7777 is a Butt Hinge that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5340-00-971-7777
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
Approved Sources 5340-00-971-7777
- Part Number
- Manufacturer
- Status
- BHMA-A156.1
- Manufacturer
- 41280 - Builders Hardware Mfrs Assn Inc (Active)
- Incomplete Reference
- Incomplete Reference
- F191US3 4 1/2X4 1/2
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Primary Buy
- Primary Buy
- F-191-4 1/2X4 1/2-US10
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 191
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- ANAI A 156.1-1981 TYPE A2133
- 80204 - American National Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-971-7777
- Characteristic
- Specifications
- FIIG
- Specifications
- A25100
- Body Width [ADAT]
- 4.500 Inches Nominal
- Hinge Mounting Type [AKER]
- Full Mortise
- Material Thickness [ABPX]
- 0.134 Inches Nominal
- Mounting Hole Diameter [ABTB]
- 0.281 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 8
- Knuckle Type [AKNB]
- Friction
- Knuckle Quantity [AKEX]
- 5
- Material And Location [ANNQ]
- Bronze Body And Steel, Corrosion Resisting Pin
- Pin Removability [AKES]
- Removable
- Pin Tip Style [AKEV]
- Flat Button
- Reversible Feature [AJNC]
- Included
- Rising Pin [AKET]
- Not Included
- Performance Type [AGLD]
- Medium Duty
- Pin Center To Body Edge Distance [AKFK]
- 2.250 Inches Nominal
- Style Designator [STYL]
- Butt
- Surface Treatment And Location [ANNR]
- Dull Bronze, Ff-H-116, Us10 Body And Dull Bronze, Ff-H-116, Us10 Pin
DLA Procurement Analysis 5340-00-971-7777
Management Data 5340-00-971-7777
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5340-00-971-7777
Freight Information 5340-00-971-7777
5340-00-971-7777 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095290. A Sub NMFC of X. It has a NMFC Description of HINGES/BUTTS NOI METAL O/T I/S. 5340-00-971-7777 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49840 which rates the freight between FCL and LCL. 5340-00-971-7777 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-971-7777 is not classified as a special type of cargo when transported by water. 5340-00-971-7777 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-971-7777
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5340-00-971-7777 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
