5340-00-879-1907
Angle Bracket
5340008791907 008791907 MS9101-33
A ridge item, usually of flat material, formed into a dihedral angle (generally a right angle) which may be reinforced; it is designed to position, align, or support an item(s) in relation to another. Excludes BRACE (as modified); BRACKET (1), MOUNTING; and BRACKET, SHELF. View more Angle Bracket
May 2023
15
Marketplace 5340-00-879-1907
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-879-1907 5+ Documents (More...)
5340-00-879-1907 (Identification) 6/4 - - - - 1.
Day 5340-00-879-1907 RQST Updated Every Day 5340-00-879-1907 RQST NE Related Documents 5340-00-879-1907
ADPEC : 5340-21-804-8236 is a Angle Bracket NATO https//www.nsnlookup.com /fsg-53/fsc-5340/us 5340-00-879-1907
Angle Bracket 5340008791907 008791907 Restrictions Approved Sources Datasheet Management https/
Restrictions 5340-00-879-1907
5340-00-879-1907 is a Angle Bracket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5340-00-879-1907
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-879-1907
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5340-00-879-1907
- Part Number
- Manufacturer
- Status
- MS9101-33
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5340-00-879-1907
- Characteristic
- Specifications
- FIIG
- Specifications
- A042A0
- First Leg Distance From Edge To Hole Center Along Length [AHRB]
- 0.250 Inches Nominal
- First Leg Distance From Edge To Hole Center Along Width [AHRA]
- 0.250 Inches Nominal
- First Leg End Radius [AJFP]
- 0.500 Inches Nominal
- First Leg Angle [CSSQ]
- 90.0 Degrees Nominal
- First Leg Length [ADLK]
- 1.115 Inches Minimum And 1.135 Inches Maximum
- First Leg Slot Length [AHLL]
- 0.278 Inches Minimum And 0.288 Inches Maximum
- First Leg Slot Width [AHLM]
- 0.200 Inches Minimum And 0.210 Inches Maximum
- First Leg Style [AJZU]
- End Radius
- First Leg Thickness [AHPW]
- 0.056 Inches Minimum And 0.068 Inches Maximum
- First Leg Hole Arrangement Style [AKAU]
- One Slot
- First Leg Width [AHQN]
- 0.485 Inches Minimum And 0.515 Inches Maximum
- Material [MATT]
- Steel Comp 321
- Material Document And Classification [MDCL]
- Ams 5510 Assn Std Single Material Response
- Second Leg Distance From Edge To Hole Center Along Width [AHLV]
- 0.250 Inches Nominal
- Second Leg End Radius [AJFQ]
- 0.500 Inches Nominal
- Second Leg Hole Arrangement Style [AKCU]
- One Slot
- Second Leg Distance From Edge To Hole Center Along Length [AHLW]
- 0.250 Inches Nominal
- Second Leg Relationship To First Leg [CSSP]
- Not Identical
- Second Leg Slot Length [AHLZ]
- 0.278 Inches Minimum And 0.288 Inches Maximum
- Second Leg Slot Width [AHMA]
- 0.200 Inches Minimum And 0.210 Inches Maximum
- Second Leg Style [AKBU]
- End Radius
- Second Leg Thickness [AHPX]
- 0.056 Inches Minimum And 0.068 Inches Maximum
- Second Leg Width [AHLF]
- 0.485 Inches Minimum And 0.515 Inches Maximum
- Second Leg Length [ADLL]
- 1.740 Inches Minimum And 1.760 Inches Maximum
- Style Designator [STYL]
- Angle
Similar Supply Items to 5340-00-879-1907
Freight Information 5340-00-879-1907
5340-00-879-1907 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5340-00-879-1907 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5340-00-879-1907 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-879-1907 is not classified as a special type of cargo when transported by water. 5340-00-879-1907 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-879-1907
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Special Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Special requirement – See specific instructions or drawings provided
