5340-00-838-6987
Padlock Set
5340008386987 008386987 A-A-59486 AA59486-1AB50S5 MS21313-132
Two or more PADLOCK which are keyed alike and/or master keyed. It may consist of two or more specific groups of PADLOCK, each group being keyed alike and/or master keyed. View more Padlock Set
November 2023
6
Marketplace 5340-00-838-6987
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-838-6987 5+ Documents (More...)
United States (US) 4. 5340-00-838-6987 Marketplace Restrictions Approved Sources Datasheet Management
Every Day 5340-00-838-6987 RQST NE Updated Every Day 5340-00-838-6987 RQST Updated Every Day 5340-00
A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master keyed
Padlock Set 5340017017730017017730,A-A-59486 Padlock Set 5340010520671010520671,A-A-59486A-A-59486 -
-59486 A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master
keyed A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master
-59486 A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master
keyed A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master
A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master keyed
A-A-59486-1IB80 AA59486-1IB80 MS21313-118 Two or more PADLOCK which are keyed alike and/or master keyed
Restrictions 5340-00-838-6987
5340-00-838-6987 is a Padlock Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5340-00-838-6987
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-838-6987
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTHD
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5340-00-838-6987
- Part Number
- Manufacturer
- Status
- AA59486-1AB50S5
- Manufacturer
- 58536 - Federal Commercial Item Description (Active)
- Definitive Standard
- Definitive Standard
- A-A-59486
- 58536 - Federal Commercial Item Description (Active)
- Incomplete Standard
- Incomplete Standard
- MS21313-132
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-838-6987
- Characteristic
- Specifications
- FIIG
- Specifications
- A03100
- Chain Length [AGFA]
- 9.000 Inches Nominal
- Construction [CQCF]
- Solid Or Laminated
- Operating Mechanism Type [BZHX]
- Pin Tumbler With Dead Bolt Locking Construction
- Individual Padlock Keying Type [CKCW]
- Keyed Alike
- Key Change Quantity [CJLR]
- 3000
- Shackle Clearance [CKDJ]
- 0.688 Inches Minimum And 1.188 Inches Maximum
- Shackle Diameter [CKDK]
- 0.241 Inches Minimum And 0.321 Inches Maximum
- Overall Height [CTHX]
- 2.844 Inches Nominal
- Overall Width [ABHC]
- 1.500 Inches Nominal
- Padlock Quantity [CKCM]
- 50
- Surface Treatment [SFTT]
- Lacquer Overall
Weapon Systems (WSDC) 5340-00-838-6987
DLA Procurement Analysis 5340-00-838-6987
- Last Stock Position:
- 9 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5340-00-838-6987
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Nov 2022
- Defense Logistics Agency (DS)
- SE
- Subscribe
- 1
- SE
- Oct 2022
- Department of the Air Force (DF)
- SE
- Subscribe
- 1
- SE
- Oct 2021
- Department of the Air Force (DF)
- SE
- Subscribe
- 1
- SE
- Oct 2020
- Department of the Air Force (DF)
- SE
- Subscribe
- 1
- SE
- Oct 2019
- Department of the Air Force (DF)
- SE
- Subscribe
- 1
- SE
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5340-00-838-6987
Freight Information 5340-00-838-6987
5340-00-838-6987 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095760. A Sub NMFC of X. It has a NMFC Description of LOCKS/LOCK SETS NOI METAL IN BBL/BX. 5340-00-838-6987 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50130 which rates the freight between FCL and LCL. 5340-00-838-6987 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-838-6987 is not classified as a special type of cargo when transported by water. 5340-00-838-6987 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-838-6987
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5340-00-838-6987 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
