5340-00-835-7263
Spring Tension Clip
5340008357263 008357263 RCS0014-8 BACC15AF8 RC50014-8
A preformed item of semirigid material designed to retain, position, fasten, or support other items, such as cable(s), access cover(s), by its own inherent spring action. It may be fastened to a structure by bolt(s), clip(s), screw(s), and the like. For items conducting electric current, see CLIP, ELECTRICAL or CLAMP, ELECTRICAL. For items which partially surround an item, see STRAP, RETAINING. For items which entirely surround an item and do not have inherent spring tension, see CLAMP, LOOP. See also CLIP, RETAINING. Do not use if a more specific item name is available. View more Spring Tension Clip
November 2023
15
Marketplace 5340-00-835-7263
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-835-7263 5+ Documents (More...)
Photo 1/2 5340-00-835-7263 Photo 2/2 - - 1.
United States (US) 4. 5340-00-835-7263 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 5340-00-835-7263
5340-00-835-7263 is a Spring Tension Clip that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5340-00-835-7263
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-835-7263
- US Air Force (FXGI)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FXKZ
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
Approved Sources 5340-00-835-7263
- Part Number
- Manufacturer
- Status
- RCS0014-8
- Manufacturer
- 08205 - Renton Coil Spring Company (Active)
- Primary Buy
- Primary Buy
- BACC15AF8
- 81205 - The Boeing Company (Active)
- Secondary Buy
- Secondary Buy
- RC50014-8
- 08205 - Renton Coil Spring Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-835-7263
- Characteristic
- Specifications
- FIIG
- Specifications
- A03100
- Distance From Loop Center To End [AZWE]
- 0.500 Inches Nominal
- Hole Diameter [AAUB]
- 0.140 Inches Nominal
- Material Document And Classification [MDCL]
- Mil-S-7947 Mil Spec Single Material Response Overall
- Material Thickness [ABPX]
- 0.025 Inches Nominal
- Material [MATT]
- Steel Comp 1095 Overall
- Length [ABRY]
- 0.500 Inches Nominal
- Loop/Holding Dimension [CJYS]
- 0.500 Inches Nominal
- Overall Height [ABKW]
- 0.810 Inches Nominal
- Width [ABGL]
- 0.440 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5340-00-835-7263
DLA Procurement Analysis 5340-00-835-7263
- Last Stock Position:
- 40 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5340-00-835-7263
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Similar Supply Items to 5340-00-835-7263
Freight Information 5340-00-835-7263
5340-00-835-7263 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 094220. A Sub NMFC of X. It has a NMFC Description of CLIPS SHEET STEEL NOI. 5340-00-835-7263 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49780 which rates the freight between FCL and LCL. 5340-00-835-7263 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-835-7263 is not classified as a special type of cargo when transported by water. 5340-00-835-7263 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-835-7263
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5340-00-835-7263 4 Records
Contracting Technical Data File (CTDF) 5340-00-835-7263 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- R
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
