5340-00-689-7213
Bumper
5340006897213 006897213 7529296
An item so designed that when attached to an object, protects that objec from damage by reducing the force of impact with another object. For external vehicular bumpers see BUMPER, VEHICULAR. Excludes GROMMET (as modified); BUSHING, NONMETALLIC; PAD, CUSHIONING and WASHER (as modified). View more Bumper
December 2025
14
Marketplace 5340-00-689-7213
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-689-7213 2+ Documents (More...)
/fsg-53/fsc-5340/us
Documents 5340-00-689-7213 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5340/us 5340
-00-689-7213 Bumper 5340006897213 006897213,7529296 Details... 7529296 BUMPER 16 EA NS Request Quotation
Bumper 5340006897213 006897213,7529296 BUMPER 30 EA NS Request Quotation Subscribe to View Vendor
Details... 7529296 BUMPER RQST NS Request Quotation Subscribe to View Vendor Details... 7529296 BUMPER
Restrictions 5340-00-689-7213
5340-00-689-7213 is a Bumper that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5340-00-689-7213
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-689-7213
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBD
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-00-689-7213
- Part Number
- Manufacturer
- Status
- 7529296
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 5340006897213
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-689-7213
- Characteristic
- Specifications
- FIIG
- Specifications
- A535L0
- Color [HUES]
- Black
- Material Document And Classification [MDCL]
- Mil-Std-417, Type R, Class Rn, Grade Rn520cfk Mil Std Single Material Response
- Material Hardness Rating [ALME]
- 50.0 Durometer Minimum And 55.0 Durometer Maximum
- Material [MATT]
- Rubber
- Shank Length [AATR]
- 0.625 Inches Nominal
- Outside/Top Flange Diameter [BXCX]
- 1.625 Inches Nominal
- Overall Height [ABKW]
- 2.375 Inches Minimum And 2.406 Inches Maximum
- Special Features [FEAT]
- Hex Rubber Flange 1.650 In. Across Flats 0.120 In. Thk
- Style Designator [STYL]
- Err-090
- Thread Size [ABUJ]
- 3/8-24
Weapon Systems (WSDC) 5340-00-689-7213
DLA Procurement Analysis 5340-00-689-7213
- Last Stock Position:
- 605 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5340-00-689-7213
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5340-00-689-7213
Freight Information 5340-00-689-7213
5340-00-689-7213 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 156660. A Sub NMFC of X. It has a NMFC Description of PLASTIC/RUBR BUMPERS/SPRINGS NOI. 5340-00-689-7213 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 84190 which rates the freight between FCL and LCL. 5340-00-689-7213 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-689-7213 is not classified as a special type of cargo when transported by water. 5340-00-689-7213 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-689-7213
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5340-00-689-7213 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
