5340-00-573-9942
Angle Bracket
5340005739942 005739942 3019M88P01
A ridge item, usually of flat material, formed into a dihedral angle (generally a right angle) which may be reinforced; it is designed to position, align, or support an item(s) in relation to another. Excludes BRACE (as modified); BRACKET (1), MOUNTING; and BRACKET, SHELF. View more Angle Bracket
May 2023
6
Marketplace 5340-00-573-9942
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-573-9942 5+ Documents (More...)
9942 (Identification) 4/7 NSN 5340-00-573-9942 (Identification) 5/7 NSN 5340-00-573-9942 (Identification
5340-00-573-9942 RQST Updated Every Day 5340-00-573-9942 RQST NE Related Documents 5340-00-573-9942
Restrictions 5340-00-573-9942
5340-00-573-9942 is a Angle Bracket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5340-00-573-9942
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-573-9942
- US Air Force (FXGI)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- NIZD
- Supplementary Collaborators:
- KE
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-00-573-9942
- Part Number
- Manufacturer
- Status
- 3019M88P01
- Manufacturer
- 07482 - General Electric Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-00-573-9942
- Characteristic
- Specifications
- FIIG
- Specifications
- A042A0
- First Leg Distance Between Hole Centers Along Length [AHQX]
- 0.100 Inches Nominal
- First Leg Distance Between Hole Centers Along Width [AHQU]
- 1.350 Inches Nominal
- First Leg Distance From Edge To Hole Center Along Length [AHRB]
- 0.230 Inches Minimum And 0.270 Inches Maximum
- First Leg Angle [CSSQ]
- 90.0 Degrees Nominal
- First Leg Corner Radius [AHQP]
- 0.230 Inches Minimum And 0.270 Inches Maximum
- First Leg Length [ADLK]
- 0.800 Inches Minimum And 0.880 Inches Maximum
- First Leg Distance From Edge To Hole Center Along Width [AHRA]
- 0.230 Inches Minimum And 0.270 Inches Maximum
- First Leg Hole Arrangement Style [AKAU]
- Two Holes
- First Leg Hole Diameter [AHLK]
- 0.274 Inches Minimum And 0.288 Inches Maximum
- First Leg Style [AJZU]
- Corner Radius
- First Leg Thickness [AHPW]
- 0.073 Inches Minimum And 0.087 Inches Maximum
- First Leg Width [AHQN]
- 1.810 Inches Minimum And 1.890 Inches Maximum
- Material [MATT]
- Steel Comp 321
- Material Document And Classification [MDCL]
- Ams 5510 Assn Std Single Material Response
- Second Leg Distance From Edge To Hole Center Along Width [AHLV]
- 0.400 Inches Minimum And 0.440 Inches Maximum
- Second Leg End Radius [AJFQ]
- 0.400 Inches Minimum And 0.440 Inches Maximum
- Second Leg Hole Arrangement Style [AKCU]
- One Slot
- Second Leg Distance From Edge To Hole Center Along Length [AHLW]
- 0.400 Inches Minimum And 0.440 Inches Maximum
- Second Leg Slot Length [AHLZ]
- 0.480 Inches Minimum And 0.520 Inches Maximum
- Second Leg Slot Width [AHMA]
- 0.210 Inches Minimum And 0.230 Inches Maximum
- Second Leg Style [AKBU]
- End Radius And Tapered
- Second Leg Thickness [AHPX]
- 0.073 Inches Minimum And 0.087 Inches Maximum
- Second Leg Length [ADLL]
- 1.980 Inches Minimum And 2.060 Inches Maximum
- Second Leg Relationship To First Leg [CSSP]
- Not Identical
- Style Designator [STYL]
- Angle
Weapon Systems (WSDC) 5340-00-573-9942
DLA Procurement Analysis 5340-00-573-9942
Management Data 5340-00-573-9942
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5340-00-573-9942
Freight Information 5340-00-573-9942
5340-00-573-9942 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5340-00-573-9942 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5340-00-573-9942 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-573-9942 is not classified as a special type of cargo when transported by water. 5340-00-573-9942 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-573-9942
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5340-00-573-9942 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
