5340-00-557-0500
Rod End Clevis
5340005570500 005570500 272S2000311-001
A forked part, having transverse hole(s) or slot(s) in each arm (prong) to accommodate a bolt, pin, or the like, and having a connection facility opposite the fork. It is designed to be attached to a shaft, rod, turnbuckle or the like by welding, threading, and/or pinning. May include provisions for locking. See also YOKE, UNIVERSAL JOINT and CONNECTOR, ROD END. For items specifically designed for aviation, see CLEVIS, ROD END, AVIATION. View more Rod End Clevis
May 2023
2
Marketplace 5340-00-557-0500
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-557-0500 5+ Documents (More...)
/fsg-53/fsc-5340/us
Photo 1/2 NSN 5340-00-557-0500 (Identification) 2/2 - - 1.
CLEVIS,ROD END 2 EA NS Request Quotation Updated Every Day 5340-00-557-0500 RQST NE Updated Every
/fsg-99/fsc-9999/fr
/fsg-99/fsc-9999/uk
/fsg-80/fsc-8010/uk
Restrictions 5340-00-557-0500
5340-00-557-0500 is a Rod End Clevis that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5340-00-557-0500
- US Air Force (FJJ5)
- Effective Date:
- 1 Jul 2001
- Former MOE Rule:
- FEE5
Approved Sources 5340-00-557-0500
- Part Number
- Manufacturer
- Status
- 272S2000311-001
- Manufacturer
- 38597 - Lockheed Martin Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-00-557-0500
- Characteristic
- Specifications
- FIIG
- Specifications
- A264A0
- Distance From Center Of Securing Pin Hole To Rod End [AKYH]
- 0.380 Inches Nominal
- Distance From Pivot Pinhole Center To Rod Connection End [AKYV]
- 1.656 Inches Nominal
- End Radius [ABPZ]
- 0.400 Inches Nominal
- Fork Depth [AKYX]
- 1.032 Inches Nominal
- Fork Span Width [AJSD]
- 0.510 Inches Minimum And 0.520 Inches Maximum
- Fork Arm Thickness [AKYW]
- 0.088 Nominal Mils And 0.098 Nominal Centimeters
- Material Document And Classification [MDCL]
- Mil-S-5000 Cond C4 Mil Spec Single Material Response Overall
- Nominal Thread Size [CQJX]
- 0.312 Inches Rod Connection
- Material [MATT]
- Steel Comp 4340 Overall
- Securing Pin Hole Diameter [AKYE]
- 0.070 Inches Nominal
- Shank Diameter [AAZE]
- 0.560 Inches Nominal
- Shank Length [AATR]
- 0.500 Inches Nominal
- Overall Height [ABKW]
- 0.800 Inches Nominal
- Overall Width [ABMK]
- 0.686 Inches Minimum And 0.716 Inches Maximum
- Style Designator [STYL]
- Clevis
- Surface Treatment Document And Classification [STDC]
- 104,Cage 38597 Mfr Ref Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Thread Class [AAJD]
- 3B Rod Connection
- Thread Direction [AAJF]
- Right-Hand Rod Connection
- Thread Length [AASA]
- 0.624 Inches Nominal Rod Connection
- Thread Series Designator [THSD]
- Unf Rod Connection
Management Data 5340-00-557-0500
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 2002
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Similar Supply Items to 5340-00-557-0500
Freight Information 5340-00-557-0500
5340-00-557-0500 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5340-00-557-0500 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5340-00-557-0500 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-557-0500 is not classified as a special type of cargo when transported by water. 5340-00-557-0500 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-557-0500
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
