5340-00-229-4349
Butt Hinge
5340002294349 002294349 A-A-50432 AA50432 TYII, CLI 3X3 1.25 MILH1237
A hinge usually with rectangularly shaped leaves. The dimension parallel to the hinge pin must be greater than the dimension transverse to the hinge pin. It may have a tension coil spring at its pivot(s) for closing action, and may have a third member between its pivot(s) to permit the door, or the like, to swing in an arc from either side. View more Butt Hinge
May 2023
4
Marketplace 5340-00-229-4349
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-229-4349 5+ Documents (More...)
/fsg-53/fsc-5340/us 5340-00-229-4349 Butt Hinge 5340002294349002294349,A-A-50432 A-A-50432AA50432 TYII
https//www.nsnlookup.com /fsg-53/fsc-5340/us 5340-00-229-4349 Butt Hinge 5340002294349002294349,A-A -
//www.nsnlookup.com /fsg-53/fsc-5340/us 5340-00-229-4349 Butt Hinge 5340002294349 002294349,A-A-50432
Account Upgrade 5340-00-229-4349Butt Hinge5340002294349 002294349 A-A-50432 AA50432 TYII, CLI 3X3 1.25
/us 5340-00-229-4349 Butt Hinge 5340002294349 002294349,A-A-50432 Account Upgrade 5340-00-229-4349Butt
Hinge5340002294349 002294349 A-A-50432 AA50432 TYII, CLI 3X3 1.25 MILH1237 https//www.nsnlookup.com
MILH1237 /us 5340-00-229-4289 Butt Hinge 5340002294289 002294289,A-A-50432 AA50432 TYIV, CLI 1.5X1.5
.625 MILH1237 Upgrade 5340-00-223-4161Butt Hinge5340002234161 002234161 A-A-50432 AA50432 TYVI, CLIII
MILH1237 /us 5340-00-229-4289 Butt Hinge 5340002294289 002294289,A-A-50432 AA50432 TYIV, CLI 1.5X1.5
.625 MILH1237 Upgrade 5340-00-223-4161Butt Hinge5340002234161 002234161 A-A-50432 AA50432 TYVI, CLIII
Restrictions 5340-00-229-4349
5340-00-229-4349 is a Butt Hinge that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5340-00-229-4349
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-00-229-4349
- Part Number
- Manufacturer
- Status
- AA50432 TYII, CLI 3X3 1.25
- Manufacturer
- 58536 - Federal Commercial Item Description (Active)
- Definitive Standard
- Definitive Standard
- A-A-50432
- 58536 - Federal Commercial Item Description (Active)
- Incomplete Standard
- Incomplete Standard
- MILH1237
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-229-4349
- Characteristic
- Specifications
- FIIG
- Specifications
- A25100
- Body Width [ADAT]
- 3.000 Inches Nominal
- Hinge Mounting Type [AKER]
- Full Mortise
- Material Thickness [ABPX]
- 0.092 Inches Nominal
- Mounting Hole Diameter [ABTB]
- 0.193 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 6
- Knuckle Type [AKNB]
- Friction
- Knuckle Quantity [AKEX]
- 5
- Material And Location [ANNQ]
- Brass Button Tip And Brass, Wrought Body And Steel, Corrosion Resisting Pin
- Reversible Feature [AJNC]
- Not Included
- Rising Pin [AKET]
- Not Included
- Performance Type [AGLD]
- Regular Duty
- Pin Center To Body Edge Distance [AKFK]
- 1.250 Inches Nominal
- Pin Removability [AKES]
- Removable
- Pin Tip Style [AKEV]
- Oval Head
- Style Designator [STYL]
- Butt
- Surface Treatment And Location [ANNR]
- Nickel Plated Overall
Similar Supply Items to 5340-00-229-4349
Freight Information 5340-00-229-4349
5340-00-229-4349 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095290. A Sub NMFC of X. It has a NMFC Description of HINGES/BUTTS NOI METAL O/T I/S. 5340-00-229-4349 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49840 which rates the freight between FCL and LCL. 5340-00-229-4349 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-229-4349 is not classified as a special type of cargo when transported by water. 5340-00-229-4349 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-229-4349
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
