5340-00-198-7577
Dust And Moisture Seal Boot
5340001987577 001987577 4108434
A flexible, nonmetallic item designed to prevent entry of dust, moisture and other contaminants into critical areas around shafts, levers, electrical wires and hoses. Sealing may be either static or dynamic. The item may include mounting hardware (support plates, clamps and the like). Excludes BELLOWS, PROTECTION; GROMMET, NONMETALLIC; and CABLE NIPPLE, ELECTRICAL. See also CAP, ELECTRICAL; CAP, PROTECTIVE, DUST AND MOISTURE SEAL; and SHIELD, ELECTRICAL CONNECTOR. View more Dust And Moisture Seal Boot
January 2023
11
Marketplace 5340-00-198-7577
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-198-7577 2+ Documents (More...)
And Moisture Seal Boot 5340001987577 4108434 A flexible, nonmetallic item designed to prevent entry
Approved Sources Datasheet Management Every Day 5340-00-198-7577 RQST Updated Every Day 5340-00-198-
Dust And Moisture Seal Boot 5340001987577 RQST NE Updated Every Day 5340-00-198-7577 RQST Updated
Every Day 5340-00-198-7577 RQST NE Related Documents 5340-00-198-7577 2+ Documents ( More... ) https
Restrictions 5340-00-198-7577
5340-00-198-7577 is a Dust And Moisture Seal Boot that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5340-00-198-7577
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-00-198-7577
- Part Number
- Manufacturer
- Status
- 4108434
- Manufacturer
- 88277 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
- 4108434
- 18355 - The Boeing Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5340-00-198-7577
- Characteristic
- Specifications
- FIIG
- Specifications
- A02000
- Base Inside Diameter [BGJZ]
- 4.312 Inches Nominal
- Base Overall Length [BGKB]
- 5.438 Inches Nominal
- Base Width [ACUU]
- 4.000 Inches Nominal
- Base Height [AJCZ]
- 0.438 Inches Nominal
- Body Height [ADAU]
- 2.187 Inches Nominal
- Body Outside Diameter [ADAR]
- 2.625 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 2.875 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Width [ABKR]
- 3.406 Inches Nominal
- Fsc Application Data [ZZZV]
- Pump Assy,Hydraulic Handle
- Material Thickness [ABPX]
- 0.094 Inches Nominal
- Material [MATT]
- Rubber Silicone Body
- Mounting Device Quantity [ACUP]
- 1 And 4
- Mounting Hole Diameter [ABTB]
- 0.187 Inches Nominal
- Mounting Method [AXGY]
- Flange And Unthreaded Hole
- Opening Inside Diameter [BGKC]
- 1.656 Inches Nominal
- Overall Height [ABKW]
- 4.125 Inches Nominal
- Style Designator [STYL]
- Thru-Hole
- Surface Treatment [SFTT]
- Any Acceptable Body
NATO Stock Numbers Related to 5340-00-198-7577
Freight Information 5340-00-198-7577
5340-00-198-7577 has freight characteristics.. 5340-00-198-7577 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 5340-00-198-7577
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- MIL-DTL-117, Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
