5340-00-105-6204
Manual Control Lever
5340001056204 001056204 11636345
A rigid item of various shapes and cross-sections, specifically designed to manually actuate and/or regulate a variety of mechanisms. It usually has an integral handgrip, knob, or the like, or provisions for the mounting of the same. It may have accommodations for locking and/or positioning. The point of fulcrum may be an integral shaft perpendicular to the axis or a through hole to provide a definite means of securing, and usually has additional accommodation(s) for attachment of CONNECTING LINK,RIGID; WIRE ROPE ASSEMBLY,SINGLE LEG; and CLEVIS,ROD END; and the like. Excludes ARM (as modified); LEVER,REMOTE CONTROL; AND BELL CRANK. View more Manual Control Lever
May 2023
4
Marketplace 5340-00-105-6204
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-105-6204 5+ Documents (More...)
BUY NE FedMall Updated Every Day 5340-00-105-6204 RQST NE Updated Every Day 5340-00-105-6204 RQST
Updated Every Day 5340-00-105-6204 RQST NE Related Documents 5340-00-105-6204 1+ Documents ( More...
Restrictions 5340-00-105-6204
5340-00-105-6204 is a Manual Control Lever that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5340-00-105-6204
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-105-6204
- US Army (A919)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBF
Approved Sources 5340-00-105-6204
- Part Number
- Manufacturer
- Status
- 11636345
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-00-105-6204
- Characteristic
- Specifications
- FIIG
- Specifications
- A524V0
- Special Features [FEAT]
- Material Is Steel Casting Grade 80-50 Spec Qq-S-681;Optional Material Is Steel Forging,Composition,1030-1050 Condition Normalized,Spec Mil-S-46172,Quench And Temper 225-250 Brinell;Optional Material Is Iron Casting Ductile,Grade 60-40-18 Or 65-45-12 Per Astm-A536;Finish No. 1.1.2.3 Plus 20.3 Of Mil-Std-171;Overall Length Is 4.820 In.;Hole 0.252 In. Dia. O.340 Deep;Hole O.156 In. Dia.;Hole 0.062 In. Dia.;Item Is Used On M551 Opposing Force Veh.
DLA Procurement Analysis 5340-00-105-6204
Management Data 5340-00-105-6204
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5340-00-105-6204
Freight Information 5340-00-105-6204
5340-00-105-6204 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5340-00-105-6204 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. 5340-00-105-6204 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5340-00-105-6204 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-105-6204 is not classified as a special type of cargo when transported by water. 5340-00-105-6204 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5340-00-105-6204 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
