5340-00-071-1392
Spring Tension Clip
5340000711392 000711392 100-200-14-23
A preformed item of semirigid material designed to retain, position, fasten, or support other items, such as cable(s), access cover(s), by its own inherent spring action. It may be fastened to a structure by bolt(s), clip(s), screw(s), and the like. For items conducting electric current, see CLIP, ELECTRICAL or CLAMP, ELECTRICAL. For items which partially surround an item, see STRAP, RETAINING. For items which entirely surround an item and do not have inherent spring tension, see CLAMP, LOOP. See also CLIP, RETAINING. Do not use if a more specific item name is available. View more Spring Tension Clip
May 2023
16
Marketplace 5340-00-071-1392
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-071-1392 5+ Documents (More...)
United States (US) 4. 5340-00-071-1392 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5340-00-071-1392 RQST Updated Every Day 5340-00-071-1392 RQST NE Related Documents
Restrictions 5340-00-071-1392
5340-00-071-1392 is a Spring Tension Clip that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5340-00-071-1392
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-071-1392
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- KE
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Mar 1995
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5340-00-071-1392
- Part Number
- Manufacturer
- Status
- 100-200-14-23
- Manufacturer
- 99378 - Atlee Of Delaware, Incorporated (Active)
- Primary Buy
- Primary Buy
Datasheet 5340-00-071-1392
- Characteristic
- Specifications
- FIIG
- Specifications
- A03100
- Material [MATT]
- Steel Comp 1065 Overall
- Material Document And Classification [MDCL]
- Sae Assn Std Single Material Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Hole Diameter [AAUB]
- 0.093 Inches Nominal
- Width [ABGL]
- 0.250 Inches Nominal
- Overall Height [ABKW]
- 0.460 Inches Nominal
- Material Thickness [ABPX]
- 0.012 Inches Nominal
- Length [ABRY]
- 0.400 Inches Nominal
- Distance From Loop Center To End [AZWE]
- 0.260 Inches Nominal
- Loop/Holding Dimension [CJYS]
- 0.376 Inches Nominal
DLA Procurement Analysis 5340-00-071-1392
Management Data 5340-00-071-1392
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5340-00-071-1392
Freight Information 5340-00-071-1392
5340-00-071-1392 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 094220. A Sub NMFC of X. It has a NMFC Description of CLIPS SHEET STEEL NOI. 5340-00-071-1392 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49780 which rates the freight between FCL and LCL. 5340-00-071-1392 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-071-1392 is not classified as a special type of cargo when transported by water. 5340-00-071-1392 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-071-1392
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5340-00-071-1392 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
