5340-00-050-6866
Loop Clamp
5340000506866 000506866 MIL-C-8603 MS21919WG40 AS21919WG40 5340PL1653549
A clamp designed to surround other item(s) such as cable(s), conduit(s), pipe(s), hose(s), or tube(s), and to fasten together or to another object or structure. Includes straight flexible items. For items specifically designed to clamp a hose to a connection to prevent leakage, see CLAMP, HOSE. See also HANGER, PIPE and CLIP, SPRING TENSION. For retaining straps with a bridge, see STRAP, RETAINING. Excludes CLAMP, ELECTRICAL; BAND, RETAINING; CLAMP (1), C; BRACKET PIPE. View more Loop Clamp
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
July 2025
July 2025
NATO Update Count
32
32
NATO Data Quality
Marketplace 5340-00-050-6866
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5340-00-050-6866 5+ Documents (More...)
MIL-C-8603 MS21919WG40 AS21919WG40 5340PL1653549 A clamp designed to surround other item(s) such as
Photo 1/2 NSN 5340-00-050-6866 (Identification) 2/2 - - 1.
MS21919WG40 CLAMP 9 EA NS Request Quotation Subscribe to View Vendor Details...
Photo 1/2 NSN 5340-00-050-6866 (Identification) 2/2 - - 1.
MS21919WG40 CLAMP 9 EA NS Request Quotation Subscribe to View Vendor Details...
Upgrade for $1 a day Upgrade your Account Upgrade 5340-01-622-1626Loop Clamp5340016221626 016221626 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
for $1 a day Upgrade your Account Upgrade 5340-01-596-6146Spec Loop Clamp5340015966146 015966146 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
Upgrade for $1 a day Upgrade your Account Upgrade 5340-01-419-5558Loop Clamp5340014195558 014195558 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
Upgrade for $1 a day Upgrade your Account Upgrade 5340-00-186-3399Loop Clamp5340001863399 001863399 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
day Upgrade your Account Upgrade 5340-01-143-6781Loop Clamp5340011436781 011436781 AS21919WDF46 MIL-C-8603
your Account Upgrade 5340-01-157-9683Loop Clamp5340011579683 011579683 SAE-AS21919 AS21919WCH40 MIL-C-8603
Restrictions 5340-00-050-6866
5340-00-050-6866 is a Loop Clamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5340-00-050-6866
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5340-00-050-6866
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBD
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Lithuania (WI01)
- Effective Date:
- 1 Mar 2001
- Poland (WP01)
- Effective Date:
- 1 May 2006
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Singapore (YJ01)
- Effective Date:
- 1 Jul 2010
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Oct 1995
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Jan 1997
- Greece (ZU01)
- Effective Date:
- 1 Sep 1994
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 5340-00-050-6866
- Part Number
- Manufacturer
- Status
- MS21919WG40
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-C-8603
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- AS21919WG40
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5340PL1653549
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5340-00-050-6866
- Characteristic
- Specifications
- FIIG
- Specifications
- A12700
- Distance From Loop Center To Tongue End [AZDC]
- 1.946 Inches Nominal
- Center To Center Distance Between Loop And Mounting Hole [AZCY]
- 1.713 Inches Minimum And 1.743 Inches Maximum
- Cushioning Environmental Protection [AAAP]
- Weather Resistant
- Diameter [ABMZ]
- 0.204 Inches Nominal
- Material Thickness [ABPX]
- 0.040 Inches Nominal
- Material [MATT]
- Rubber Chloroprene Class Cr Cushion
- Material [MATT]
- Steel Comp 1008 Band Or Steel Comp 1009 Band Or Steel Comp 1015 Band Or Steel Comp 1018 Band Or Steel Comp 1020 Band
- Loop Inside Diameter [BZTN]
- 2.485 Inches Minimum And 2.515 Inches Maximum
- Material Document And Classification [MDCL]
- Ams 3209 Assn Std Single Material Response Cushion
- Overall Width [ABMK]
- 0.490 Inches Minimum And 0.510 Inches Maximum
- Tongue Hole Type [AAAL]
- Round, Unthreaded
- Style Designator [STYL]
- Surface Treatment Document And Classification [STDC]
- Qq-P-416 Ty 1 Cl 2 Fed Spec Single Treatment Response Band
- Surface Treatment [SFTT]
- Cadmium Band
Weapon Systems (WSDC) 5340-00-050-6866
DLA Procurement Analysis 5340-00-050-6866
- Last Stock Position:
- 841 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5340-00-050-6866
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- AW
- AIRBORNE WARNING AND CONTROL SYSTEM (AWACS) 411L
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5340-00-050-6866
5340-99-350-5393 5340-99-668-6383 5340-12-177-8176 5340-34-041-0935 5340-99-437-8227 5340-12-366-0925 5340-21-905-5797 5340-99-468-2209 5340-37-522-8398 5340-99-547-6641 5340-99-753-5372 5340-99-826-0725 5340-12-367-4403 5340-66-066-4214 5340-99-436-2002 5340-14-571-9162 5340-34-030-9779 5340-99-104-4630
Freight Information 5340-00-050-6866
5340-00-050-6866 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5340-00-050-6866 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5340-00-050-6866 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5340-00-050-6866 is not classified as a special type of cargo when transported by water. 5340-00-050-6866 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5340-00-050-6866
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5340-00-050-6866 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
