5331-01-078-6452

O-Ring

5331010786452 010786452 MIL-DTL-25988/1 L1120 2-337 M25988/1-337 337-11647 2-337L449-6 PRP568-337-1133-60 AA-337TH1047 B63115-337 337-11646 PRP337-11646 11-337-8450-60 L0449 2-337 2-337 L449-65 C007-337 H733-4-337 MIL-R-25988 AS568-337MIL-R-25988/1 2-337L677-70

A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see PACKING,PREFORMED. For noncircular items with a round cross-section, see SEAL,NONMETALLIC ROUND SECTION and RUBBER,ROUND SECTION. View more O-Ring

Managed by United States

NSN Created on 17 Jun 1979

Data Last Changed
November 2023

NATO Update Count
38

NATO Data Quality

5331-01-078-6452 O-RING 5331010786452 010786452 1/1 — 5331-01-078-6452 Photo 1/1

Marketplace 5331-01-078-6452

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

M25988-1-337 O-RING 99 EA NS

Subscribe to View Vendor Details...

5330-01-078-6452 O-RING 6 EA NS

Subscribe to View Vendor Details...

MIL-R-25988 O-RING 979 EA NS

Subscribe to View Vendor Details...

M259881-337 O-RING 2 EA NS

Subscribe to View Vendor Details...

MILR25988 O-RING 1128 EA NS

Subscribe to View Vendor Details...

MIL-R-25988 O-RING 23 EA NS

Updated Every Day

5331-01-078-6452 RQST NE

Updated Every Day

5331-01-078-6452 RQST

Updated Every Day

5331-01-078-6452 RQST NE

Restrictions 5331-01-078-6452

5331-01-078-6452 is a O-Ring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5331-01-078-6452

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5331-01-078-6452

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

US Navy (N9BZ)
Effective Date:: 1 Dec 2013
Supplementary Collaborators:: GGGT; AMC 1 AMSC G IMC Z IMCACTY GH

France (ZF01)
Effective Date:: 1 May 2015

United Kingdom (ZK01)
Effective Date:: 1 Dec 1999

Approved Sources 5331-01-078-6452

Part Number
Manufacturer
Status
M25988/1-337: 81349 - Military Specifications (Active); Definitive Standard; RNCC 2 RNVC 2 DAC 4
MIL-DTL-25988/1: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
L1120 2-337: 02697 - Parker-Hannifin Corp (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 1
337-11647: 25184 - Parker Hannifin Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
MIL-R-25988: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
AS568-337MIL-R-25988/1: 81343 - Society Of Automotive Engineers Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
2-337L677-70: 02697 - Parker-Hannifin Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
2-337L677-70: 83259 - Parker-Hannifin Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
2-337L449-6: 02697 - Parker-Hannifin Corp (Active); Transferred; RNCC E RNVC 8 DAC 3
PRP568-337-1133-60: 77308 - Parco, Llc (Active); Transferred; RNCC E RNVC 8 DAC 4
AA-337TH1047: 95272 - Stillman Seal Corporation (Active); Transferred; RNCC E RNVC 8 DAC 4
B63115-337: 77308 - Parco, Llc (Active); Transferred; RNCC E RNVC 8 DAC 5
AA-337TH1047: SW461 - Hutchinson Seal De Mexico Stillman (Active); Transferred; RNCC E RNVC 8 DAC 5
337-11646: 25184 - Parker Hannifin Corporation (Active); Transferred; RNCC E RNVC 8 DAC 4
PRP337-11646: 25184 - Parker Hannifin Corporation (Active); Transferred; RNCC E RNVC 8 DAC 4
11-337-8450-60: 81168 - Strohmeyer, Julie A. (Active); Transferred; RNCC E RNVC 8 DAC 4
L0449 2-337: 02697 - Parker-Hannifin Corp (Active); Transferred; RNCC E RNVC 8 DAC 4
2-337 L449-65: 02697 - Parker-Hannifin Corp (Active); Transferred; RNCC E RNVC 8 DAC 4
C007-337: 81755 - Lockheed Martin Corporation (Active); Transferred; RNCC E RNVC 8 DAC 1
H733-4-337: 07096 - Burke Industries Purosil Div (Active); Transferred; RNCC E RNVC 8 DAC 4

Datasheet 5331-01-078-6452

Characteristic
Specifications
FIIG: A510X0
Elongation Percentage [ANYN]: 125 Maximum
Center Hole Diameter [ADYT]: 2.951 Inches Minimum And 2.999 Inches Maximum
Cross-Sectional Height [ADVN]: 0.205 Inches Minimum And 0.215 Inches Maximum
Hardness Rating [CQFM]: 70.0 Shore Durometer A Nominal
Material [MATT]: Rubber Fluorosilicone Class Fq

Weapon Systems (WSDC) 5331-01-078-6452

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5331-01-078-6452

Last Stock Position:: 602 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5331-01-078-6452

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Jan 2023: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): F; R; Refer To S009093238; S009093238

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 5331-01-078-6452

Freight Information 5331-01-078-6452

5331-01-078-6452 has freight characteristics managed by France.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5331-01-078-6452 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5331-01-078-6452 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5331-01-078-6452 is not classified as a special type of cargo when transported by water. 5331-01-078-6452 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5331-01-078-6452

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; No Requirements

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag; Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 5331-01-078-6452 1 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE5E816V1829: 24 Dec 2015; Subscribe; 282; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5331-01-078-6452 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
