5330-01-509-0298
Plain Seal
5330015090298 015090298 29520292
A pliable rubber or composition ring-shaped element, split or jointless (solid) not encased in a metal shell, but having a spring, spreader and/or molded-in reinforcement. It is designed to be pressmounted between fixed and movable or moving parts to form a tight and effective seal. View more Plain Seal
April 2025
6
Marketplace 5330-01-509-0298
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-509-0298 5+ Documents (More...)
5330-01-509-0298 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-509-0298
Plain Seal 5330015090298 015090298,29520292 29520292 A pliable rubber or composition ring-shaped element
Restrictions 5330-01-509-0298
5330-01-509-0298 is a Plain Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-01-509-0298
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-509-0298
- US Army (A919)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Spain (YB01)
- Effective Date:
- 1 Jun 2004
- Canada (ZC01)
- Effective Date:
- 1 Jul 2006
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 2009
Approved Sources 5330-01-509-0298
- Part Number
- Manufacturer
- Status
- 29520292
- Manufacturer
- 73342 - Allison Transmission Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 5330-01-509-0298
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- End Item Identification [AGAV]
- 2520-01-201-4784 Transmission With C
- Accommodated Shaft Diameter [ABVM]
- 5.363 Inches Minimum And 5.443 Inches Maximum
- Construction [CQCF]
- One-Piece
- Housing Bore Diameter [CPCW]
- 5.534 Inches Minimum And 5.624 Inches Maximum
- Material [MATT]
- Rubber Synthetic Overall
- Seal Width [ADUC]
- 0.155 Inches Minimum And 0.165 Inches Maximum
- Part Name Assigned By Controlling Agency [CXCY]
- Seal-Lip External
Weapon Systems (WSDC) 5330-01-509-0298
DLA Procurement Analysis 5330-01-509-0298
- Last Stock Position:
- 519 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-509-0298
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5330-01-509-0298
Freight Information 5330-01-509-0298
5330-01-509-0298 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194090. A Sub NMFC of X. It has a NMFC Description of WASHERS/SEALS. 5330-01-509-0298 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-01-509-0298 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-509-0298 is not classified as a special type of cargo when transported by water. 5330-01-509-0298 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-509-0298
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5330-01-509-0298 10 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE5EM19V0591
- 29 Oct 2018
- Subscribe
- 1061
- Subscribe
- Subscribe
- Subscribe
- SPE5EM17V4274
- 18 Apr 2017
- Subscribe
- 307
- Subscribe
- Subscribe
- Subscribe
- SPE5EM17V1095
- 17 Nov 2016
- Subscribe
- 218
- Subscribe
- Subscribe
- Subscribe
- SPE5EM16V4151
- 21 Apr 2016
- Subscribe
- 221
- Subscribe
- Subscribe
- Subscribe
- SPE5EM16V1537
- 18 Dec 2015
- Subscribe
- 211
- Subscribe
- Subscribe
- Subscribe
- SPE5EM15V4042
- 14 Apr 2015
- Subscribe
- 218
- Subscribe
- Subscribe
- Subscribe
- SPE5EM14V2881
- 09 Apr 2014
- Subscribe
- 220
- Subscribe
- Subscribe
- Subscribe
- SPM5EM13V1828
- 11 Apr 2013
- Subscribe
- 534
- Subscribe
- Subscribe
- Subscribe
- SPM5EM13V1364
- 11 Mar 2013
- Subscribe
- 200
- Subscribe
- Subscribe
- Subscribe
- SPM5EM13V0970
- 22 Jan 2013
- Subscribe
- 154
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5330-01-509-0298 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
