5330-01-413-8543
Gasket
5330014138543 014138543 02957 5330007346886
A deformable material which prevents the passage of matter through the joint formed when two faces are joined. It may be metallic or nonmetallic, lubricated or impregnated, solid or hollow cross section. It may be made to any predetermined dimension and shape. Excludes flat disks, items made of felt material and items having joints. For round metal and plastic items with an aperture and a solid rectangular cross section, see WASHER, FLAT; SHIM; BEARING, WASHER, THRUST; and SPACER RING. Excludes DISK, VALVE; SEAL, NONMETALLIC ANGLE; SEAL, NONMETALLIC CHANNEL; SEAL, NONMETALLIC SPECIAL SHAPED SECTION; SHIELDING GASKET, ELECTRONIC; and RING, SEALING JAR. View more Gasket
October 2025
8
Marketplace 5330-01-413-8543
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-413-8543 5+ Documents (More...)
Quotation Subscribe to View Vendor Details... 5330-01-413-8543 GASKET 1 EA NS Request Quotation 02957
Updated 56 Days Ago 02957 GASKET 1 EA NS Request Quotation 02957 GASKET 3 EA NS Request Quotation 02957
Restrictions 5330-00-734-6886 DEMIL: A | DEMILI https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-413-8543
Gasket 5330014138543 014138543,,02957 for $1 a day Upgrade your Account Upgrade 5330-01-413-8543Gasket5330014138543
/000/00C3887/02957 Managed by United Kingdom NSN Created on 3 Jul 1995 Data Last RQST NE Updated Every
/000/00C3887/02957 Managed by United Kingdom NSN https//www.nsnlookup.com /fsg-58/fsc-5820/uk 5820-99
https//www.nsnlookup.com /fsg-76/fsc-7610/tr 7610-27-020-5265 Book 7610270205265 270205265,7610-TJ1-02957
7610-27-020-5265 5+ https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-734-6886 Gasket 5330007346886
Updated Every Day 7610-27 https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-734-6886 Gasket 5330007346886
-99-983-1760 Flat Washer 5310999831760 999831760,02957 8317Bookcase7110218998317 218998317MMD-1206-02957
Restrictions 5330-01-413-8543
5330-01-413-8543 is a Gasket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5330-01-413-8543
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBS
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
Approved Sources 5330-01-413-8543
- Part Number
- Manufacturer
- Status
- 02957
- Manufacturer
- 14153 - Defense Logistics Agency (Active)
- Primary Buy
- Primary Buy
- 5330007346886
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5330007346886
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5330-01-413-8543
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Aperture Diameter [ABVL]
- 6.750 Inches Nominal
- Bolt Hole Quantity [AECS]
- 8
- Cross-Sectional Shape Style [AAGR]
- Solid Single Or Composition
- Cross-Sectional Thickness [ADVM]
- 0.026 Inches Minimum And 0.036 Inches Maximum
- Environmental Attribute Code [ENAC]
- Asbestos Alternative Products
- Hole Diameter [AAUB]
- 0.469 Inches Nominal
- Material Document And Classification [MDCL]
- Astm F104 712100E33-6 Assn Std Single Material Response Overall
- Outside Diameter [ABKV]
- 8.875 Inches Minimum
Weapon Systems (WSDC) 5330-01-413-8543
DLA Procurement Analysis 5330-01-413-8543
- Last Stock Position:
- 771 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-413-8543
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5330-00-734-6886
- 0
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5330-01-413-8543
Freight Information 5330-01-413-8543
5330-01-413-8543 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-01-413-8543 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-01-413-8543 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-413-8543 is not classified as a special type of cargo when transported by water. 5330-01-413-8543 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-413-8543
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- ASTM-D4727, Fiberboard used as a Stiffener on Both Sides of Item
- --
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5330-01-413-8543 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
