5330-01-374-9264
Gasket
5330013749264 013749264 8725296 NON-ASBESTOS 8725296 5330006783313
A deformable material which prevents the passage of matter through the joint formed when two faces are joined. It may be metallic or nonmetallic, lubricated or impregnated, solid or hollow cross section. It may be made to any predetermined dimension and shape. Excludes flat disks, items made of felt material and items having joints. For round metal and plastic items with an aperture and a solid rectangular cross section, see WASHER, FLAT; SHIM; BEARING, WASHER, THRUST; and SPACER RING. Excludes DISK, VALVE; SEAL, NONMETALLIC ANGLE; SEAL, NONMETALLIC CHANNEL; SEAL, NONMETALLIC SPECIAL SHAPED SECTION; SHIELDING GASKET, ELECTRONIC; and RING, SEALING JAR. View more Gasket
September 2024
21
Marketplace 5330-01-374-9264
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-374-9264 5+ Documents (More...)
GASKET 56 EA NS Request Quotation 8725296 GASKET 58 EA NS Request Quotation 8725296 NON-ASBESTOS GASKET
GASKET 56 EA NS Request Quotation 8725296 GASKET 58 EA NS Request Quotation 8725296 NON-ASBESTOS GASKET
Day 5330-00-678-3313 RQST Updated Every Day 5330 https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-374-9264
Gasket 5330013749264 013749264 your Account Upgrade 5330-01-374-9264Gasket5330013749264 013749264
/fsg-47/fsc-4730/us 4730 https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-678-3313 Gasket 5330006783313
62644730013746264013746264 is a straight fitting https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-374-9264
Gasket 8725296 NON-ASBESTOSRNCC: 1 | RNVC: 2 | DAC: 5 1 May 1993 5330-00-291-1720 Nonmetallic Round
Gasket 8725296 NON-ASBESTOSRNCC: 1 | RNVC: 2 | DAC: 5 1 May 1993 5330-00-291-1720 https//www.nsnlookup.com
/fsg-53 Packing and Gasket Materials (FSC 5330) 1 Jan 1900 5330-01-374-9264 Gasket 8725296 NON-ASBESTOSRNCC
Restrictions 5330-01-374-9264
5330-01-374-9264 is a Gasket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-01-374-9264
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-374-9264
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Dec 2006
- Spain (YB01)
- Effective Date:
- 1 Oct 1998
- Singapore (YJ01)
- Effective Date:
- 6 Dec 1995
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Turkey (ZW01)
- Effective Date:
- 1 Aug 2000
Approved Sources 5330-01-374-9264
- Part Number
- Manufacturer
- Status
- 8725296 NON-ASBESTOS
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Source Control
- Source Control
- 8725296
- 0V9V2 - Ordex Inc (Active)
- Primary Buy
- Primary Buy
- 8725296 NON-ASBESTOS
- 73165 - Federal-Mogul Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8725296 NON-ASBESTOS
- 79788 - Eagle-Picher Industries Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5330013749264
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 5330006783313
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5330-01-374-9264
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Aperture Width [ADUE]
- 1.594 Inches Nominal
- Aperture Length [ADUF]
- 1.880 Inches Nominal
- Bolt Circle Diameter [ABKG]
- 2.560 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Solid Single Or Composition
- Cross-Sectional Thickness [ADVM]
- 0.054 Inches Minimum And 0.074 Inches Maximum
- Environmental Attribute Code [ENAC]
- Asbestos Alternative Products
- Hole Diameter [AAUB]
- 0.380 Inches Nominal
- Material [MATT]
- Rubber Overall
- Overall Length [ABHP]
- 3.240 Inches Nominal
- Overall Width [ABMK]
- 2.250 Inches Nominal
- Special Features [FEAT]
- Non-Asbestos Material
Weapon Systems (WSDC) 5330-01-374-9264
DLA Procurement Analysis 5330-01-374-9264
- Last Stock Position:
- 2525 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-374-9264
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5330-01-374-9264
Freight Information 5330-01-374-9264
5330-01-374-9264 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194050. A Sub NMFC of X. It has a NMFC Description of GASKETS/RINGS PLUMBING FIXTURES. 5330-01-374-9264 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 78100 which rates the freight between FCL and LCL. 5330-01-374-9264 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-374-9264 is not classified as a special type of cargo when transported by water. 5330-01-374-9264 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-374-9264
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5330-01-374-9264 4 Records
Contracting Technical Data File (CTDF) 5330-01-374-9264 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
