5330-01-374-8945
Gasket
5330013748945 013748945 8351863 NON-ASBESTOS 5330007360277
A deformable material which prevents the passage of matter through the joint formed when two faces are joined. It may be metallic or nonmetallic, lubricated or impregnated, solid or hollow cross section. It may be made to any predetermined dimension and shape. Excludes flat disks, items made of felt material and items having joints. For round metal and plastic items with an aperture and a solid rectangular cross section, see WASHER, FLAT; SHIM; BEARING, WASHER, THRUST; and SPACER RING. Excludes DISK, VALVE; SEAL, NONMETALLIC ANGLE; SEAL, NONMETALLIC CHANNEL; SEAL, NONMETALLIC SPECIAL SHAPED SECTION; SHIELDING GASKET, ELECTRONIC; and RING, SEALING JAR. View more Gasket
October 2025
20
Marketplace 5330-01-374-8945
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-374-8945 2+ Documents (More...)
Photo 1/2 NSN 5330-01-374-8945 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5330-01-374-8945 RQST Updated Every Day 5330-01-374-8945 RQST NE Related
Gasket 5330013748945 013748945, Upgrade your Account Upgrade 5330-01-374-8945Gasket5330013748945
013748945 8351863 NON-ASBESTOS 5330007360277 Documents 5330-01-374-8945 1+ Documents ( More... ) https
Restrictions 5330-01-374-8945
5330-01-374-8945 is a Gasket that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-01-374-8945
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-374-8945
- US Army (A919)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBF
- US Marine Corps (MC47)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- MC10
- Austria (WB01)
- Effective Date:
- 1 Dec 2006
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Belgium (ZB01)
- Effective Date:
- 1 Nov 1998
- Germany (ZG01)
- Effective Date:
- 1 Aug 1993
- United Kingdom (ZK01)
- Effective Date:
- 1 Jul 2000
- Portugal (ZP01)
- Effective Date:
- 1 Mar 2014
- Denmark (ZS01)
- Effective Date:
- 1 May 1996
- Norway (ZT01)
- Effective Date:
- 1 Dec 1996
- Greece (ZU01)
- Effective Date:
- 1 May 2006
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5330-01-374-8945
- Part Number
- Manufacturer
- Status
- 8351863 NON-ASBESTOS
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Incomplete Reference
- Incomplete Reference
- 5330007360277
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5330007360277
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5330-01-374-8945
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Aperture Diameter [ABVL]
- 5.600 Inches Nominal
- Bolt Circle Diameter [ABKG]
- 6.120 Inches Minimum And 6.400 Inches Maximum
- Bolt Hole Quantity [AECS]
- 16
- Criticality Code Justification [CRTL]
- Matt
- Cross-Sectional Shape Style [AAGR]
- Solid Single Or Composition
- Cross-Sectional Thickness [ADVM]
- 0.014 Inches Minimum And 0.018 Inches Maximum
- Environmental Attribute Code [ENAC]
- Asbestos Alternative Products
- Material Document And Classification [MDCL]
- Mil-G-12803,Type 7 Mil Spec All Material Responses Overall Or Astm F104f712100e33-6 Assn Std All Material Responses Overall Or Astm F104f712400e45-6 Assn Std All Material Responses Overall Or Astm F104f723200e43-4 Assn Std All Material Responses Overall Or Astm F104f723200e43-6 Assn Std All Material Responses Overall
- Material [MATT]
- Plastic Overall Or Rubber Overall Or Leather Overall Or Fiber Overall
- Largest Bolt Hole Diameter [BYWX]
- 0.406 Inches Nominal
- Reference Number Differentiating Characteristics [ZZZY]
- As Differentiated By Non-Asbestos Material
- Smallest Bolt Hole Diameter [BYWW]
- 0.250 Inches Nominal
- Outside Diameter [ABKV]
- 7.200 Inches Nominal
Weapon Systems (WSDC) 5330-01-374-8945
DLA Procurement Analysis 5330-01-374-8945
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-374-8945
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5330-00-736-0277
- 0
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5330-01-374-8945
Freight Information 5330-01-374-8945
5330-01-374-8945 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194050. A Sub NMFC of X. It has a NMFC Description of GASKETS/RINGS PLUMBING FIXTURES. 5330-01-374-8945 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 78100 which rates the freight between FCL and LCL. 5330-01-374-8945 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-374-8945 is not classified as a special type of cargo when transported by water. 5330-01-374-8945 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-374-8945
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- ASTM-D4727, Fiberboard used as a Stiffener on Both Sides of Item
- --
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5330-01-374-8945 1 Records
Contracting Technical Data File (CTDF) 5330-01-374-8945 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- K
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
