5330-01-248-8833
Wiper Ring
5330012488833 012488833 MS28776-35
A circular, single or multipiece, rigid, metallic or nonmetallic item having a centrally located hole with a sharp edge on the inside periphery. It is supplied in various cross-sectional shapes and is designed to be installed in a cylinder, shock strut, or similar device to remove excess oil, dirt, ice, and/or foreign material from a piston, ram, or sliding rod. Excludes PACKING, PREFORMED; RING, PISTON; and SEAL RING, METAL. View more Wiper Ring
September 2025
10
Marketplace 5330-01-248-8833
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-248-8833 2+ Documents (More...)
MS28776-35 RING,WIPER 1 EA NS Request Quotation Updated Every Day 5330-01-248-8833 RQST NE Updated Every
Day 5330-01-248-8833 RQST Updated Every Day 5330-01-248-8833 RQST NE Related Documents 5330-01-248-8833
-66-056-2649 RQST Updated Every Day 5330-66-056 https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-248-8833
Wiper Ring 5330012488833 012488833 MS28776-35 RING,WIPER 4 EA NS Request Quotation Subscribe to
Restrictions 5330-01-248-8833
5330-01-248-8833 is a Wiper Ring that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-01-248-8833
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-248-8833
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Aug 1997
- New Zealand (ZE01)
- Effective Date:
- 1 Oct 1997
- France (ZF01)
- Effective Date:
- 1 Apr 2000
Approved Sources 5330-01-248-8833
- Part Number
- Manufacturer
- Status
- MS28776-35
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5330-01-248-8833
- Characteristic
- Specifications
- FIIG
- Specifications
- A08400
- Cross-Sectional Shape Style [AAGR]
- Outside Grooved, Straight Face
- Material Document And Classification [MDCL]
- Mil-S-6049 Mil Spec Single Material Response Overall
- Material Thickness [ABPX]
- 0.140 Inches Nominal
- Outer Edge Thickness [ACXK]
- 0.109 Inches Nominal
- Material [MATT]
- Copper Alloy Overall
- Inside Diameter [AARX]
- 3.919 Inches Nominal
- Ring Style [ACXD]
- Concentric
- Outside Diameter [ABKV]
- 4.094 Inches Nominal
- Specification/Standard Data [ZZZK]
- 96906-Ms28776 Government Standard
DLA Procurement Analysis 5330-01-248-8833
Management Data 5330-01-248-8833
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Sep 2006
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Sep 2004
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- V
- Discontinued Without Replacement
- V
- Defense Logistics Agency (DS)
- I
- V
- Discontinued Without Replacement
- V
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5330-01-248-8833
Freight Information 5330-01-248-8833
5330-01-248-8833 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-01-248-8833 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-01-248-8833 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-248-8833 is not classified as a special type of cargo when transported by water. 5330-01-248-8833 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5330-01-248-8833 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
