5330-01-216-7424
Brake Coolant Seal
5330012167424 012167424 23018080
April 2025
10
Marketplace 5330-01-216-7424
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-216-7424 1+ Documents (More...)
EA NS Request Quotation Updated Every Day 5330-01-216-7424 RQST NE Updated Every Day 5330-01-216-7424
RQST Updated Every Day 5330-01-216-7424 RQST NE Related Documents 5330-01-216-7424 1+ Documents ( More
Restrictions 5330-01-216-7424
5330-01-216-7424 is a Brake Coolant Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-01-216-7424
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-216-7424
- US Army (A919)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Lithuania (WI01)
- Effective Date:
- 1 Mar 2001
- Malaysia (YW01)
- Effective Date:
- 1 Sep 2005
- Canada (ZC01)
- Effective Date:
- 1 Jun 2006
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jan 2005
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 5330-01-216-7424
- Part Number
- Manufacturer
- Status
- 23018080
- Manufacturer
- 73342 - Allison Transmission Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 5330-01-216-7424
- Characteristic
- Specifications
- FIIG
- Specifications
- A23900
- General Characteristics Item Description [TEXT]
- Seal Is Steel,Sae 1008 Thru 1020,Or Steel Sae 1111 Thru 1117 And Steel Sae 1211 Thru 1215; Phosphate Finish Per Tps 11600 Fscm 73342;45 Degree Inside Angle; 7.175 In. Min And 7.185 In. Max Center Hole Dia; 7.410 In. Flanged Body Outside Dia; 7.830 In. Peripheral Dia; 0.140 In. Height; 0.048 In. Min And 0.052 In. Max Rim Surface Width
Weapon Systems (WSDC) 5330-01-216-7424
DLA Procurement Analysis 5330-01-216-7424
- Last Stock Position:
- 997 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-216-7424
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5330-01-216-7424
Freight Information 5330-01-216-7424
5330-01-216-7424 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5330-01-216-7424 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5330-01-216-7424 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-01-216-7424 is not classified as a special type of cargo when transported by water. 5330-01-216-7424 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-216-7424
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5330-01-216-7424 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE5EJ18V8444
- 11 Sep 2018
- Subscribe
- 301
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ18V5035
- 23 Apr 2018
- Subscribe
- 186
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ18V4148
- 20 Mar 2018
- Subscribe
- 332
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ18V2854
- 02 Feb 2018
- Subscribe
- 211
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ18V2056
- 26 Dec 2017
- Subscribe
- 110
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ17V5533
- 13 Jun 2017
- Subscribe
- 172
- Subscribe
- Subscribe
- Subscribe
- SPM5EJ13V1501
- 19 Mar 2013
- Subscribe
- 400
- Subscribe
- Subscribe
- Subscribe
- SPM5EJ13V1442
- 13 Mar 2013
- Subscribe
- 283
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5330-01-216-7424 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
