5330-01-213-8350
Gasket
5330012138350 012138350 9510M48P01 798285
A deformable material which prevents the passage of matter through the joint formed when two faces are joined. It may be metallic or nonmetallic, lubricated or impregnated, solid or hollow cross section. It may be made to any predetermined dimension and shape. Excludes flat disks, items made of felt material and items having joints. For round metal and plastic items with an aperture and a solid rectangular cross section, see WASHER, FLAT; SHIM; BEARING, WASHER, THRUST; and SPACER RING. Excludes DISK, VALVE; SEAL, NONMETALLIC ANGLE; SEAL, NONMETALLIC CHANNEL; SEAL, NONMETALLIC SPECIAL SHAPED SECTION; SHIELDING GASKET, ELECTRONIC; and RING, SEALING JAR. View more Gasket
November 2023
10
Marketplace 5330-01-213-8350
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-213-8350 5+ Documents (More...)
GASKET 37 EA NS Request Quotation Updated Every Day 5330-01-213-8350 RQST NE Updated Every Day 5330-
01-213-8350 RQST Updated Every Day 5330-01-213-8350 RQST NE Related Documents 5330-01-213-8350 5+ Documents
www.nsnlookup.com /fsg-40/fsc-4010/us 4010-00-954-4001 Single Leg Wire Rope Assembly 4010009544001 798285
Gasket 5330012138350 012138350,9510M48P01 Single Leg Wire Rope Assembly 4010009544001 Upgrade your
01-200-5180 DEMIL: A | DEMILI : 1 | CRITICALITY https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-213-8350
Gasket 5330012138350 012138350,9510M48P01 Wire Rope Assembly4010009544001 009544001 798285 https
https//www.nsnlookup.com /fsg-49/fsc-4920/us 4920-01-699-2648 Tester Mission Equipment Support Set WP-798285
Approved Sources 4920-01-699-2648 Part NumberManufacturerStatusWP-798285-2 27899 - Williamsrdm, Inc.
Upgrade your Account Upgrade 4010-00-954-4001Single Leg Wire Rope Assembly4010009544001 009544001 798285
www.nsnlookup.com /fsg-40/fsc-4010/us 4010-00-954-4001 Single Leg Wire Rope Assembly 4010009544001 798285
Restrictions 5330-01-213-8350
5330-01-213-8350 is a Gasket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-01-213-8350
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-213-8350
- US Air Force (FXGI)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Singapore (YJ01)
- Effective Date:
- 1 May 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2008
- Greece (ZU01)
- Effective Date:
- 1 May 2008
Approved Sources 5330-01-213-8350
- Part Number
- Manufacturer
- Status
- 9510M48P01
- Manufacturer
- 07482 - General Electric Company (Active)
- Source Control
- Source Control
- 798285
- 83259 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 5330-01-213-8350
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Elongation Percentage [ANYN]
- 125 Maximum
- Aperture Diameter [ABVL]
- 0.200 Inches Minimum And 0.208 Inches Maximum
- Bolt Hole Quantity [AECS]
- 2
- Center To Center Distance Between Bolt Holes Along Length [ADUZ]
- 1.110 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Metal And Synthetic Rubber
- Cross-Sectional Thickness [ADVM]
- 0.126 Inches Minimum And 0.150 Inches Maximum
- Gage Ring Thickness [ADWF]
- 0.090 Inches Minimum And 0.100 Inches Maximum
- Hole Diameter [AAUB]
- 0.218 Inches Minimum And 0.226 Inches Maximum
- Material [MATT]
- Aluminum Alloy 6061 Overall And Rubber Fluorocarbon Class Fpm Overall
- Material Document And Classification [MDCL]
- Ams4027 Assn Std 1St Material Response Overall And Mil-R-83248 Mil Spec 2Nd Material Response Overall
- Overall Length [ABHP]
- 1.610 Inches Minimum And 1.650 Inches Maximum
- Special Features [FEAT]
- Retainer Annodized Ams 2472
Weapon Systems (WSDC) 5330-01-213-8350
DLA Procurement Analysis 5330-01-213-8350
- Last Stock Position:
- 689 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-01-213-8350
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5330-01-213-8350
Freight Information 5330-01-213-8350
5330-01-213-8350 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-01-213-8350 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-01-213-8350 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-01-213-8350 is not classified as a special type of cargo when transported by water. 5330-01-213-8350 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-01-213-8350
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Any Suitable Container
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5330-01-213-8350 3 Records
Contracting Technical Data File (CTDF) 5330-01-213-8350 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
