5330-01-041-1301
Plain Encased Seal
5330010411301 010411301 300879 4188102 B60-90-7027
A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes PACKING WITH RETAINER. View more Plain Encased Seal
May 2025
14
Marketplace 5330-01-041-1301
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-041-1301 5+ Documents (More...)
Photo 1/3 NSN 5330-01-041-1301 (Identification) 2/3 NSN 5330-01-041-1301 (Identification) 3/3 -
Updated Every Day 5330-01-041-1301 RQST NE Updated Every Day 5330-01-041-1301 RQST Updated Every Day
- Upgrade for $1 a day Upgrade your Account Upgrade 5330-01-699-2568Gasket5330016992568 016992568 300879
Plain Encased Seal 5330010411301 010411301 300879 https//www.nsnlookup.com /fsg-53/fsc-5310/fr
//www.nsnlookup.com /fsg-53/fsc-5310/fr 5310-14-238-3284 Hexagon Plain Nut 5310142383284142383284 300879
- Upgrade for $1 a day Upgrade your Account Upgrade 5330-01-699-2568Gasket5330016992568 016992568 300879
https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-699-2568 Gasket 5330016992568 016992568,300879 300879
Plain Encased Seal 5330010411301 010411301 300879 - Upgrade for $1 a day Upgrade your Account Upgrade
www.nsnlookup.com /fsg-59/fsc-5998/us 5998-01-128-8533 Circuit Card Assembly 5998011288533011288533 300879
enable JavaScript in your web browser . 5998-01-128 -8533Circuit Card Assembly5998011288533 011288533 300879
Restrictions 5330-01-041-1301
5330-01-041-1301 is a Plain Encased Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-01-041-1301
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-01-041-1301
- Malaysia (YW01)
- Effective Date:
- 1 Sep 2005
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 5330-01-041-1301
- Part Number
- Manufacturer
- Status
- 4188102
- Manufacturer
- 80212 - Bae Systems Land & Armaments L.P. (Active)
- Primary Buy
- Primary Buy
- 300879
- H0G87 - Wiba Zevenaar B.V. (Active)
- Secondary Buy
- Secondary Buy
- B60-90-7027
- 80201 - Skf Usa Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4188102
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 5330-01-041-1301
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Accommodated Shaft Diameter [ABVM]
- 2.350 Inches Minimum And 2.360 Inches Maximum
- Case Style [BHHL]
- Recessed
- Housing Bore Diameter [CPCW]
- 4.765 Inches Minimum And 4.797 Inches Maximum
- Material [MATT]
- Steel Case
- Material [MATT]
- Rubber Synthetic Sealing Element
- Seal Width [ADUC]
- 1.084 Inches Minimum And 1.104 Inches Maximum
- Sealing Element Style [CTQC]
- Angular
- Temp Rating [ABJH]
- -40.0 Deg Fahrenheit And 180.0 Deg Fahrenheit
NATO Stock Numbers Related to 5330-01-041-1301
Freight Information 5330-01-041-1301
5330-01-041-1301 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-01-041-1301 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5330-01-041-1301 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-01-041-1301 is not classified as a special type of cargo when transported by water. 5330-01-041-1301 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
