5330-01-035-0995
Gasket
5330010350995 010350995 703544
A deformable material which prevents the passage of matter through the joint formed when two faces are joined. It may be metallic or nonmetallic, lubricated or impregnated, solid or hollow cross section. It may be made to any predetermined dimension and shape. Excludes flat disks, items made of felt material and items having joints. For round metal and plastic items with an aperture and a solid rectangular cross section, see WASHER, FLAT; SHIM; BEARING, WASHER, THRUST; and SPACER RING. Excludes DISK, VALVE; SEAL, NONMETALLIC ANGLE; SEAL, NONMETALLIC CHANNEL; SEAL, NONMETALLIC SPECIAL SHAPED SECTION; SHIELDING GASKET, ELECTRONIC; and RING, SEALING JAR. View more Gasket
May 2023
4
Marketplace 5330-01-035-0995
Request a Quotation from participating marketplace vendors
Related Documents 5330-01-035-0995 5+ Documents (More...)
Updated Every Day 5330-01-035-0995 RQST NE Related Documents 5330-01-035-0995 5+ Documents ( More...
) https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-035-0995 Gasket 5330010350995 010350995,703544
/fsg-53/fsc-5340/tr
https//www.nsnlookup.com /fsg-53/fsc-5340/tr 5340-27-012-3391 Retaining Clip 5340270123391270123391 W 703544
Gasket 5330010350995 010350995,703544 Documents 5330-01-035-0995 3+ Documents ( More... ) https
5840-99-831-3611El Modification Kit5840998313611 https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-035-0995
Gasket 5330010350995 010350995,703544 319-4452Ring Spacer5365123194452 123194452 703544 https//
403101 enable JavaScript in your web browser . 5365-12-319-4452Ring Spacer5365123194452 123194452 703544
403101 enable JavaScript in your web browser . 5365-12-319-4452Ring Spacer5365123194452 123194452 703544
403101 enable JavaScript in your web browser . 5365-12-319-4452Ring Spacer5365123194452 123194452 703544
403101 enable JavaScript in your web browser . 5365-12-319-4452Ring Spacer5365123194452 123194452 703544
Restrictions 5330-01-035-0995
5330-01-035-0995 is a Gasket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5330-01-035-0995
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- KE
Approved Sources 5330-01-035-0995
- Part Number
- Manufacturer
- Status
- 703544
- Manufacturer
- 35012 - Ge Aviation Systems Llc (Active)
- Primary Buy
- Primary Buy
- 703544
- 058R3 - Ge Aviation Systems Llc (Replaced)
- Original Design
- Original Design
- 703544
- 19623 - Ge Aviation Systems Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5330-01-035-0995
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Aperture Length [ADUF]
- 3.880 Inches Nominal
- Aperture Width [ADUE]
- 1.000 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Solid Single Or Composition
- Cross-Sectional Thickness [ADVM]
- 0.060 Inches Nominal
- Material [MATT]
- Rubber Synthetic Overall
- Outside Corner Bevel Length Along Length [ADUQ]
- 0.120 Inches Minimum And 0.150 Inches Maximum
- Outside Corner Bevel Length Along Width [ADUP]
- 0.120 Inches Minimum And 0.150 Inches Maximum
- Inside Corner Radius [ADPQ]
- 0.120 Inches Nominal
- Material Document And Classification [MDCL]
- Cohrlastic R-10470 Fscm 71643 Mfr Ref Single Material Response Overall
- Overall Length [ABHP]
- 4.220 Inches Minimum And 4.260 Inches Maximum
- Overall Width [ABMK]
- 1.320 Inches Minimum And 1.360 Inches Maximum
- Style Designator [STYL]
- Non-Circular
- Temp Rating [ABJH]
- -100.0 Deg Fahrenheit And 500.0 Deg Fahrenheit
DLA Procurement Analysis 5330-01-035-0995
Management Data 5330-01-035-0995
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5330-01-035-0995
Freight Information 5330-01-035-0995
5330-01-035-0995 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-01-035-0995 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-01-035-0995 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-01-035-0995 is not classified as a special type of cargo when transported by water. 5330-01-035-0995 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
