5330-00-841-6976
Plain Encased Seal
5330008416976 008416976 7710085 21173 410303
A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes PACKING WITH RETAINER. View more Plain Encased Seal
July 2025
26
Marketplace 5330-00-841-6976
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-841-6976 5+ Documents (More...)
Photo 1/3 NSN 5330-00-841-6976 (Identification) 2/3 NSN 5330-00-841-6976 (Identification) 3/3 -
Quotation Updated Every Day 5330-00-841-6976 RQST NE Updated Every Day 5330-00-841-6976 RQST Updated
3854-21173 A tubular shaped item with a round or hexagon peripheral shape having two flat bearing surfaces
JavaScript in your web browser . 5365-99-221-2280Sleeve Spacer5365992212280 992212280A3854-211733854-21173
https//www.nsnlookup.com /fsg-53/fsc-5340/es 5340-33-210-4800 Bow Handle 5340332104800332104800 212-21173
Plain Encased Seal 5330008416976 008416976 8 Jun 1993 Data Last Changed January 2023 NATO https
) https//www.nsnlookup.com /fsg-53/fsc-5340/uk 5340-99-215-3749 Guard 5340992153749992153749,JL/A2-21173
Plain Encased Seal 5330008416976 008416976 6165 Stuffing Tube 5975013276165013276165 21173 https
//www.nsnlookup.com /fsg-51/fsc-5110/es 5110-33-003-6145 Hand File 5110330036145 330036145,410303 410303
https//www.nsnlookup.com /fsg-53/fsc-5305/fr 5305-14-353-5110 Vis 5305143535110 143535110,410303 410303
Restrictions 5330-00-841-6976
5330-00-841-6976 is a Plain Encased Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-00-841-6976
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-841-6976
- US Army (A919)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBF
- US Marine Corps (MC47)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- MC10
- Austria (WB01)
- Effective Date:
- 1 Aug 2006
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Jan 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5330-00-841-6976
- Part Number
- Manufacturer
- Status
- 7710085
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Source Control
- Source Control
- 21173
- 80201 - Skf Usa Inc. (Active)
- Primary Buy
- Primary Buy
- 410303
- 9E942 - Federal-Mogul Corp Engine And (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5330008416976
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5330-00-841-6976
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Accommodated Shaft Diameter [ABVM]
- 2.125 Inches Nominal
- Case Style [BHHL]
- Square
- Housing Bore Diameter [CPCW]
- 3.003 Inches Minimum And 3.007 Inches Maximum
- Material [MATT]
- Leather Sealing Element A
- Material [MATT]
- Leather Sealing Element B
- Material [MATT]
- Steel Case
- Outside Diameter [ABHE]
- 3.005 Inches Nominal
- Seal Width [ADUC]
- 0.688 Inches Minimum And 0.719 Inches Maximum
- Sealing Element Style [CTQC]
- Vertical-Angular
- Surface Treatment [SFTT]
- Plastic Case
- Temp Rating [ABJH]
- -250.0 Deg Fahrenheit
Weapon Systems (WSDC) 5330-00-841-6976
DLA Procurement Analysis 5330-00-841-6976
- Last Stock Position:
- 155 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-00-841-6976
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5330-00-841-6976
Freight Information 5330-00-841-6976
5330-00-841-6976 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5330-00-841-6976 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5330-00-841-6976 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-00-841-6976 is not classified as a special type of cargo when transported by water. 5330-00-841-6976 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-841-6976
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-32033, Lubricating Oil, General Purpose Preservative (Water Displacing, Low Temperature)
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- No Requirement
- Not Applicable
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- 100
- --
Procurement History 5330-00-841-6976 3 Records
Contracting Technical Data File (CTDF) 5330-00-841-6976 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- K
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
