5330-00-712-0229
Packing With Retainer
5330007120229 007120229 7120229
An item composed of a compressible nonmetallic ring which may be loosely fitted into a noncompressible retaining ring, or may be of one piece construction with the compressible ring molded and/or mechanically connected to the retainer. It is specifically designed to form a fluid tight seal when compressed by a packing nut, gland, and the like, between fixed surfaces and a cylindrical item passing through it. Excludes SEAL,PLAIN,ENCASED. View more Packing With Retainer
May 2023
6
Marketplace 5330-00-712-0229
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-712-0229 2+ Documents (More...)
RQST NE Updated Every Day 5330-00-712-0229 RQST Updated Every Day 5330-00-712-0229 RQST NE Related Documents
5330-00-712-0229 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-712-0229
Day 5330-27-022-9672 RQST NE Related Documents https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-712-0229
Packing With Retainer 5330007120229 007120229 $1 a day Upgrade your Account Upgrade 5330-00-712
Restrictions 5330-00-712-0229
5330-00-712-0229 is a Packing With Retainer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-00-712-0229
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-712-0229
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5330-00-712-0229
- Part Number
- Manufacturer
- Status
- 7120229
- Manufacturer
- 19204 - Army, United States Department Of (Active)
- Primary Buy
- Primary Buy
Datasheet 5330-00-712-0229
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Construction [CQCF]
- One-Piece
- Material [MATT]
- Plastic Retainer
- Material [MATT]
- Rubber Synthetic Packing
- Outside Diameter [ABHE]
- 7.353 Inches Minimum And 7.375 Inches Maximum
- Retainer Inside Diameter [AFFW]
- 7.000 Inches Minimum And 7.018 Inches Maximum
- Retainer Thickness [ADTJ]
- 0.346 Inches Minimum And 0.366 Inches Maximum
- Packing Ring Cross-Sectional Diameter [ADTK]
- 0.180 Inches Minimum And 0.200 Inches Maximum
- Packing Inside Diameter [AFFX]
- 6.994 Inches Nominal
NATO Stock Numbers Related to 5330-00-712-0229
Freight Information 5330-00-712-0229
5330-00-712-0229 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-00-712-0229 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-00-712-0229 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-00-712-0229 is not classified as a special type of cargo when transported by water. 5330-00-712-0229 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-712-0229
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- A-A-1507, Chipboard Sheet used as a Stiffener on Both Sides of Item
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
